• Model NO.：QC12Y-8X3200
• QC12y-8X3200：Hydraulic Guillotine Swing Beam Shearing Machine
• Shear Thickness：8mm
• Shear Width：3200mm
• Noload Strokes：10mm
• Adjustment Range of Backguage：20-600mm
• Main Motor：7.5kw
• Size：3110X1400X1450mm
• Weight：3500kgs
• Brand：China Brand
• Color：Your Required
• Transport Package：Wooden Case
• Specification：CE, ISO9001
• Trademark：UNI-TECH
• Origin：Shandong, China
• HS Code：8462392000
• Production Capacity：200sets,Month

ModelShear size(TxW) (mm)Shear angleNoload strokes
(times/min)Adjustment
range of backguage(mm)Main motor power(kw)Net weight
(kg)Dimensions (LxWxH) (mm)QC12Y-4X20004X20001°30′2020-600428002560X1400X1450QC12Y-4X25004X25001°30′2020-600435003110X1400X1450QC12Y-6x25006X25001°30′1820-6007.560003040X1610X1620QC12Y-6x32006X32001°30′1420-6007.572003840X1610X1620QC12Y-6x40006X40001°30′1020-6007.5100004640X1705X1700QC12Y-6x50006X50001°30′520-6007.5130005790X2155X1900QC12Y-8x25008X25001°30′1420-6001165003140X1610X1620QC12Y-8x32008X32001°30′1020-6001178003840X1610X1620QC12Y-8x40008x40001°30′820-60011110004680X1705X1700QC12Y10x250010x25001°48′1020-6001570003350X2050X1950QC12Y-10x320010x32001°48′820-60015110004050X2050X1790QC12Y-10x400010x40001°48′820-60018.5140004920X2250X1790QC12Y-12x250012x25001°48′1020-80018.578003320X2050X1790QC12Y-12x320012x32001°48′820-80018.5120001020X2050X17900QC12Y-12x400012x40001°48′720-80018.5160004850X2400X2200QC12Y-16x250016x25002°820-80030150003300X2300X2150QC12Y-16x400012x40002°720-80030230004800X2300X2150QC12Y-16x320016x32002°720-80030160004100X2300X2150QC12Y-16x400016x40002°620-80030230004800X2300X2150QC12Y-20x250020x25002°820-80045160003300X2300X2650QC12Y-20x320020x32002°520-80045250004100X2350X2710QC12Y-20x400020x40002°30′420-80045300004850X2400X2200Technical Features1TypeNC Hydraulic Guillotine Type2Cutting Length3200mm3Cutting Chickness8mm(mild steel at 450Mpa)4Shearing Angle with Indicate0.5~2 degree adjustable5Number of stroke per minute12 times/min6Throat depth80mm7Stroke back gauge750mm8Main motor7.5kw9NC control systemType: E10 , made in China WITH HANGING ARM
 10Main Electric elements in CabinetSIEMENS 11Seal in the cylindersNOK, 12Hydraulic pumpCHENJIE , from SHANGHAI13Main hydraulic ValveOMG-USA
 14ConnectingFerrule15With upper &bottom blade1300mm x 6 pcs, 6Crw2si16OthersFront protection,
side protection with Micro-switch
Back protection with two pairs of  electric light .
 17G.W.7500KGS18Overall Dimensions(appr,):3850X1990X205019Packing 20Delivery time45 days after received 30% T/T deposit21Payment 30%T/T deposit, 70% T/T before shipment22Price ( FOB ShangHai ) STANDARD CONFIGURATION OF HYDRAULIC SHEARING MACHINE EXPORT:
1. E21 ELECTRONIC DIGITAL:NANJING ESTUN CO.
2. MAIN ELECTRIC PARTS: GERMANY SIMENIS
3.LIMITED SWITCH,BUTTON:FRANCE SCHNEIDER
4. LOWER NOISE,GEAR-WHEEL PUMP:SHANGHAI CHENGJIE CO.
5. HYDRAULIC SYSTEM: OMG, USA
6.CASTING CONNECTOR:GERMANY JS CO.
7.MATERIAL OF BLADES:6CrW2Si
8.SEALING RINGS: JANPAN VALQUA CO.
9.ELECTRIC BOX:POWER OFF WHEN OPEN THE DOOR

Optional equipments:

1. Light curtain
2. NR12

Warranty:
What about the spare part if the machine break down?
==about the machine break down, normally our policy will be as the under way
   1) Our quality guarantee time is 12 months since the machine on board
   2) During this period, if the machine break down owing our machine itself quality problem,  we will prepare the spare parts and send to you by free within 5 days. all these will be by free.
  3) If the break down is caused by the mis operation,  we of course will supply you the spare parts, but we have to charge you the costs prices.
