Roller Shutter Roll Forming Machine

Hangzhou Zhongyuan Machinery Factory
  • Type：Rolling Machine
  • Forging Forming Method：Cold Roll Forming
  • Power Source：Electric
  • Feature：Automation
  • Certification：ISO9001, CE
  • Warranty：12 Months

Base Info

  • Model NO.：ZYYX
  • Customized：Customized
  • Advantage：Use Widely
  • Condition：New
  • Control System：Mitsubishi PLC & Converter
  • Machine Size：About 6*1.3*1.6m
  • Machine Weight：About 4t
  • Operation Language：English or as Per Client`S Required
  • Rollers Material：No.45 Forged Steel with Hard Chrome
  • Shafts for Rollers：Grand Twice, 72mm Diameter Solid Steel
  • Cutting Style：Automatic Cut to Length
  • Cutter Material：Cr12 Mould Steel with Quench Treatment
  • Machine Type：Roller Shutter Roll Forming Machine
  • Main Motor：7.5kw
  • Transport Package：1*40gp Container for One Machine
  • Specification：CE SGS BV
  • Trademark：Zhongyuan
  • Origin：China
  • HS Code：84552210
  • Production Capacity：10sets,Month

Description

ItemSpecification TypeColor steel sheet or galvanized steel sheetMaterialThickness(mm)0.4-0.8 Yield strength(mpa)235Roller material45#Chrome steelForming speed(m/min)About 20 (excluding in cutting time)Speed adjusting modeAC FrequencyRoller drive                                               Decelerating motor + Chain driveCutting modeHydraulic cuttingCutter material Cr12 mold steel Length measurementEncoderControl modeMitsubishi PLCMain motor power(kw)7.5KW   (Depend on final design)Hydraulic station power 2.2K W   (Depend on final design)Total power(kw)9.7KWUncoiler's loading capacityMax. Capacity: 3000kgsMachine`s sizeAbout 6*1.3*1.6m  (Depend on final design)Machine weightAbout 4000kgs
Components of machine:Decoiler1set   Feeding & guiding device1setMain roll forming machine1setHydraulic cutting system1setPLC Controlling system1setRun out table 1set

Process:
Decoiling the sheet → Leveling sheet→ Roll forming→ Measure length and cutting→ the Purline to the supporter



Packing:
1. One 40GP container for loading one set machine with mechanical decoiler.
2. Main machine body and decoiler is load naked (tighten to container with steel wire rope).
3. Spare parts and operating tools are loading in tooling box.

Delivery : about 50 days after received advaced payment


We customize your machines! To customize machine, we would love to know:
1. Profile drawing
2. Raw material: the width(1250mm?), thickness(0.3-0.7mm?), and yield strength of steel coil.
3. Voltage: designed per your requirement
4. Configuration requirement: Hydraulic or manual decoiler/ stacker

Have no idea about them?
We will be glad to recommend the lacol popular profile for you----Just let us know your country!


Why us?
1.  Customize roll forming machines since 2003.
2.  Capacity: 12-15 sets/month
3.  Delivery: in only 5-8 weeks for urgent order
4.  Company occupies 6650, in which 5650 for workshops
5.  Have our own tool center. 12 sets CNC machines.
6. Technician can be sent to your factory to install the machine and train your workers
