• Model NO.：GTQ-5000A
• Power Source：Electric
• Cutting Mode：Saw Cutting
• Transport Package：Plywood Exporting Package
• Specification：160KG 850*850*1950MM
• Trademark：HST
• Origin：Jinan, Shandong, China
• HS Code：9024109000
• Production Capacity：1500 Sets,Month

Basic Info.

Model NO. GTQ-5000A Power Source Electric Cutting Mode Saw Cutting Transport Package Plywood Exporting Package Specification 160KG 850*850*1950MM Trademark HST Origin Jinan, Shandong, China HS Code 9024109000 Production Capacity 1500 Sets/Month

Product Description

GTQ-5000A Precision Metallographic Sample Cutting Machine


1. Application:
GTQ-5000A Precision cutting machine is suitable for metal, electronic components, ceramics, crystal, alloy, rock samples, ore, concrete, organic materials, bio-materials (tooth, bone) and other materials for precise cutting without distortion . The device positioning accuracy; speed range; strong cutting ability; strong circulation cooling system; can be preset feed rate; menu-driven control; LCD; easy to operate control; automatic cutting reduces operator fatigue, to ensure that the test sample production consistency; large, bright room with a safety switch cut. Grinding wheel can be adjusted up and down the distance, in order to facilitate subsequent loss cutting wheel. Is one of the ideal equipment and mining enterprises, scientific research institutes to prepare high-quality specimens.

2. Main specifications:

Model	GTQ-5000A
Feed speed	0 ~ 1.5mm/s (adjusted step length 0.01mm)
Grinding wheel speed	1950rpm
The largest travel	Z-axis 50mm; Y-axis 200mm;X-axis(manual) 50mm
cutting sheet size	200 x 32 x 0.5mm
Cutting power	1500W
Power supply	380V 50HZ
