Automatic Square Downspout Pipe Cold Forming Line/Steel Round Down Pipe Roll Forming Machinery with ISO9001/Ce/SGS/Soncap

Hangzhou Zhongyuan Machinery Factory
  • Type：Rolling Machine
  • Forging Forming Method：Cold Roll Forming
  • Power Source：Electric
  • Feature：Automation
  • Certification：ISO9001, CE
  • Warranty：24 Months

Base Info

  • Model NO.：ZYYX
  • Customized：Customized
  • Advantage：Work Flexible
  • Condition：New
  • Machine Color：Made-to-Order
  • Sheet Forming Machine：About 20m,Min
  • Main Motor Power：5.5kw
  • Hydraulic Station Power：2.2kw
  • Uncoiler′s Loading Capacity：5 Tons
  • Machine Size：About 10*1.8*1.5m
  • Weight：6500kgs
  • Cutter Material：Cr12 Mould Steel
  • Brand Name：Zhongyuan
  • Rollers Material：#45 Steel with 0.05mm Hard Chrome
  • Transport Package：1*40gp Container for One Machine
  • Specification：CE SGS BV
  • Trademark：zhongyuan
  • Origin：China
  • HS Code：84552210
  • Production Capacity：10sets,Month

Description


                                                                                     Automatic Steel Line Forming MachineItemSpecificationMaterialTypePre-painted steel coil & galvanized coilsThickness (mm)0.4-0.7Width (mm)500-1300Yield strength (mpa)235-345Roller material45#Chrome steelForming speed(m/min)About 20Speed adjusting modeAC FrequencyRoller drive                                               Decelerating motor + Chain driveCutting modeHydraulic cuttingCutter material Cr12 mold steel Length measurementEncoderControl modeMitsubishi PLCOperating modeButton + Mitsubishi Touch screenMain motor power (kw)5.5 kw (Depend on final design)Hydraulic station power 2.2 kw (Depend on final design)Total power (kw)7.7 kwUncoiler's loading capacityMax. Capacity: 5000kgs
(can be increased to be 10T)Machine`s sizeAbout 10*1.8*1.5m
(Depend on final design)Components of machineDecoiler1set  Feeding & guiding device1setMain roll forming machine1setHydraulic cutting system1set Controlling system1set Run out table 1set  Process flow:

Decoiler -- Feeding & Guiding -- Roll Forming-- Hydraulic Cutting - Product to Run Out Table
Automatic Square Downspout Pipe Cold Forming Line/Steel Round Down Pipe Roll Forming Machinery with ISO9001/Ce/SGS/Soncap
Automatic Square Downspout Pipe Cold Forming Line/Steel Round Down Pipe Roll Forming Machinery with ISO9001/Ce/SGS/Soncap
Automatic Square Downspout Pipe Cold Forming Line/Steel Round Down Pipe Roll Forming Machinery with ISO9001/Ce/SGS/Soncap
Automatic Square Downspout Pipe Cold Forming Line/Steel Round Down Pipe Roll Forming Machinery with ISO9001/Ce/SGS/Soncap


Why choose this line forming machine?
1.  Manufacturing roll forming machine since 2003
2.  With ISO,SGS,BV and CE certificate
3.  2 year quality warranty
4.  Introduced Mitsubishi PLC with touch screen. Friendly man-machine interaction.
5.  Design by 15 years experienceD R&D members.
6.  Technician can be sent to your factory to install the machine and train your workers
7.  Export to more than 20 countries.

Automatic Square Downspout Pipe Cold Forming Line/Steel Round Down Pipe Roll Forming Machinery with ISO9001/Ce/SGS/Soncap
Automatic Square Downspout Pipe Cold Forming Line/Steel Round Down Pipe Roll Forming Machinery with ISO9001/Ce/SGS/Soncap

 Please feel free to contact us!
