• Customized：Customized
• Advantage：Easy to Maintenance
• Condition：New
• Thickness：0.8-1.5mm
• Length：0.5-3m
• Transport Package：Shipping, Rain-Roof
• Specification：800*1000*12000
• Trademark：Shengrui
• Origin：Zhangjiagang City
• HS Code：8455221000
• Production Capacity：10 Sets,Month

Basic Info.

Customized Customized Advantage Easy to Maintenance Condition New Thickness 0.8-1.5mm Length 0.5-3m Transport Package Shipping, Rain-Roof Specification 800*1000*12000 Trademark Shengrui Origin Zhangjiagang City HS Code 8455221000 Production Capacity 10 Sets/Month

Product Description

Factory selling price customized design PLC control drawer slide rail roll forming machine

Description	Drawer Slide/Telescopic Channel Rolling Machines
Material	Q235 or Stainless Steel
Thickness	0.8-1.5mm
Length	0.5-3M
Product Optional	Drawer slides in 30mm, 32mm, 35mm, 37mm, 42mm, 45mm, 53mm, etc
Feature	3-fold Ball Bearing
Main Motor Power	11Kw
Forming Speed	6-10m/Min
Shaft Diameter	50mm
Electrical System	Delta PLC Control
Machine Size	800*1000*12000mm
Weight	2.5T

Full Drawer Slide Rail Prodution Line:

Item Name	Decription	Quantity
Roll Forming Machine	12/14 Nos. Roll; with Punching & Cutting Mould;-for inner slide, middle slide, outer slide	3 sets
Ball Cage Production Line	25T punch press + feeder + motor decoiler	1 set
Auto Ball Assembling Device	For ball cage & steel balls & middle slide & oiling	1 set
Outer Slide Oil Adding Device	For outer slide oiling	1 set
Ball Pressing Machine	For plastic strip assembling with steel balls	1 set
Rivet Assembling Machine	For rivet assembling with plastic piece	1 set
End Bending Power Press	With Bending Mould -for outer slide end bending	1 set
Adjustment Power Press	Final step for QC; with Adjustment Mould - for slides tighten or loosen	3 sets
