High Speed Pulley Type Wire Drawing Machine for Nail Making

Hangzhou Suntech Machinery Co., Ltd.
  • Type：LW Pulley Type Metal Drawing Machine
  • Usage：Wire, Rope Wire, Prestressed Steel Wire, Standard Parts
  • Metal Material：Steel
  • Outlet Diameter：0.5-4.5mm
  • Max.Inlet Wire Dia.：6.5mm
  • Block Dia.：560mm

Base Info

  • Max. Number of Block：12
  • Certification：ISO
  • Condition：New
  • Material：Low Carbon Steel Wire
  • Quantity of Block：According to Requirements
  • Transport Package：Wooden Pallet with Film
  • Specification：1700*1150*1750
  • Trademark：SUNTECHMACH
  • Origin：China

Description

Model (Block diameter)

300

350

400

450

500

560

600

700

800

900

1200

Strength of inlet wire (MPa)

≤1250

Number of Block

2~11

2~11

2~11

2~12

2~12

2~12

2~12

2~9

2~9

2~9

2~9

Maximum diameter of inlet wire (mm)

2.8

3.5

4.2

5

5.5

6.5

8

10

12.7

14

16

Minimum diameter of outlet wire (mm)

0.5

0.6

0.75

1

1.2

1.4

1.6

2.2

2.6

3

5

Highest drawing speed (m/s)

 ~25

 ~20

 ~20

 ~16

 ~15

 ~15

 ~12

 ~12

 ~8

 ~7

 ~6

Drawing power (kw)

7.5~18.5

11~22

11~30

15~37

22~45

22~55

30~75

45~90

55~110

90~132

110~160
