• Model NO.：64S
• Production Capacity：500sets

Basic Info.

Model NO. 64S Production Capacity 500sets

Product Description

A.Description of goods:


Model	64S	164S
Number of Heading Station	4	4
Forging Force (kgs)	35000	210000
Maximum Cut off Diameter (mm)	8	18
Maximum Cut off Length (mm)	80	195
Product Shank Diameter (mm)	3-6	10-16
Max Die kick out stroke (mm)	70	178
Max punch knockout stroke (mm)	12	40
Main Ram Stroke (mm)	110	260
Main Die Size (mm)	50x85L	100X190L
Punch die dims (mm)	40x90L	75X185L
Cut-off die dims (mm)	30x45L	60X90L
Main motor power (KW)	15	55
Output (pcs/min)	40-210	70-100
Die  pitch (mm)	60	120
Shank Length of blank (mm)	10-65	70-100
Approx. Weight (kgs)	8000	45000

We are the biggest dealer in China.
We have engaged in exporting more than 20 years.
80% fasteners machine in INDIA Import from us.
Such as Deepak , Empire ,Poojafore , LPS they all use our machines.
We engaged in exporting good quality products. We can give you the best price and best after-sale services.
If you have any questions, we can send engineer to your city solve problem for you.

For any questions,please feel free to contact me.
Look forward to cooperate with you.

Best regards,
Levi
