• Model NO.：CY-SD300
• Coating Speed：0-800 mm , Minute
• Max. Drying Temperature ：150c
• Temperature Accuracy：+,-1c
• Heating Zone Length：710mm
• Reeling/Unreeling Shaft：75mm
• Keyword：Slot Die Roll Coater
• Warranty：One Year
• Transport Package：Wooden Box
• Specification：coating width 250mm
• Trademark：CY
• Origin：Zhengzhou, China
• HS Code：8486202200
• Production Capacity：210 Sets Per Month

Basic Info.

Model NO. CY-SD300 Coating Speed 0-800 mm / Minute  Max. Drying Temperature  150c Temperature Accuracy +/-1c Heating Zone Length 710mm Reeling/Unreeling Shaft 75mm Keyword Slot Die Roll Coater Warranty One Year Transport Package Wooden Box Specification coating width 250mm Trademark CY Origin Zhengzhou, China HS Code 8486202200 Production Capacity 210 Sets Per Month

Product Description

Slot-Die Roll to Roll Coating System ( Max. 250mm Wide) with Precision Slurry Feeding Pump -

 is a CE Certified automatic slot-die coating system with a compact footprint that is less than 6'x3'. It is perfect for making uniform coatings from 1~300 micron thick.


Working Voltage	208 - 240 VAC, 50/60 Hz, Single Phase
Max. Power Consumption	5 KW ( 50A Air breaker required )
Slot Die Coating	The slot die is perfect for uniform film coating of 1 micron and up to 300-micron thickness. By changing the shim size with various patterns, you would be able to produce continuous, intermittent, or even grid coatings that match the shim patterns.
Slurry Feeding Pump	MSK-156 slurry feeding screw pump with 4 liters tank is included 24DC Input, 500W 0.5~0.8MPa compress gas is required. Slurry feed rate: 0.1 - 150 rpm (or 0.023 - 34.5 mL/min) Stirring speed: 27 rpm
Shim (Spacer)	0.2mm, 0.3mm, 0.4mm, 0.5mm, 0.6mm & 0.8mm thick shims are included for producing films with various thickness.
Max. Coating Width	250 mm
Max. Coating Length	Depends on the coating and substrate thickness. Typically, 10um thick foil with 100um coating can get 600 meters of electrode length coated per run.
Coating Speed	0-800 mm / minute
Minimum Thickness & Precision	1 µm ±1%  ( dried film )
Max. Drying Temperature	150°C
Heating	Forced convection hot air  (IR + UV heating is available upon request)
Temperature Accuracy	±1°C
Heating Zone Length	710mm (28")
Reeling/Unreeling Shaft	75mm (ID)
Max. Reeling/Unreeling Diameter	250mm (OD)
Compressed Air	0.5-0.8 MPa (Air compressor not included. )
Product Dimensions	Coater: L 1750 mm*W 950 mm*H 1060 mm Slurry Feeding Pump: W 660*D 200*H 660 mm
Compliance	CE Certified
Warranty	One Year limited warranty with lifetime support
