• Model NO.：CNCSG
• Cutting Thickness：1-300mm
• Cutting Speed：50-9000mm,Min
• Position：20m,Min
• Drive Mode：Double Side, AC Servo Motor
• CNC Controller：Hypertherm Edge PRO
• Plasma Source：Hypertherm, Kjellberg
• Transport Package：Plywood Case and Tray
• Specification：ISO:2008, GB, International Standard
• Trademark：Tayor
• Origin：China
• HS Code：8456901000
• Production Capacity：1000 Sets,Year

Technical specification
Cutting Width (mm)
2200
2700
3200
4200
5200
Can be customized
Track Width (mm)
3000
3500
4000
5000
6000
800mm less than width
Cutting Length (m)
2m less than track length
Suggested cutting thickness(mm)
Oxy-fuel: 6-120(Max 300mm)/ Plasma: 1-80
Basic components
Cutting Mode
Plasma / Oxy-fuel
Drive Motor Number
Dual-side
Cutting Torch Number
Customization
Driving Motor
Servo motor
CNC Controller
SJTU-SK/Micro EDGE/EDGE pro/KP
Available Plasma Power
Hypertherm/Thermadyne/ Kjellberg /TAYOR LGK
Nesting software
FASTCAM
Power voltage
3× 380V± 10% 50Hz or according to user' s local condition
Operation language
MultilanguageMultilanguage
