Xinyida Automatic Cyclindical LNG Tank Grinding Machines Group for Mirror Effective
Anhui Xinyida Polishing Machine Co., Ltd.- Certification:ISO, CE
- Condition:New
- Voltage:380V
- Application:LNG Tank Polishing
- Transport Package:Carton Protection in Plywood Cage
- Trademark:Xinyida
Base Info
- Model NO.:JY-LNG
- Origin:China
- HS Code:846090200
- Production Capacity:60 Sets,Month
Description
Basic Info.
Model NO. JY-LNG Origin China HS Code 846090200 Production Capacity 60 Sets/MonthProduct Description
LNG tank polishing machine for outer polishingProduct Description
Polishing of the outer surface of the LNG cylinder barrel. The equipment is connected to the conveying line, and the gas cylinder enters the loading mechanism of the barrel polishing machine through the conveying line. The barrel section is polished by the horizontal automatic passage mode, and the motor is directly connected to the reducer to drive the roller to rotate, thereby driving the barrel section to advance spirally. The polishing head adopts the electric screw to pre-adjust the upper and lower positions of the grinding head, and the manual screw is required to adjust the position of the driven wheel to adapt to the cylinder of different diameters. The grinding head pre-presses the surface of the cylinder section through the constant pressure device, and the barrel section is spiraled. During the advancement process, the polishing head continuously grinds the surface of the barrel section, thereby realizing the polishing function of the barrel section surface.
.
Main Technical Parameters
Machine dimension | L*W*H(in: mm): 9200 *1500 * 1500 |
Machine weight | 4500KGS |
Input power | 30KW |
Control system | PLC/CNC |
Polishing materials | Nylon Wheel, Cloth Wheel, Thousand Impeller, and etc. |
Thousand Impeller specs | φ250mm*50mm |
Machining accuracy | surface roughness Ra≤0.3μm |
Climbing pressure | Pre-pressed cylinder |
Conveyor line speed | 8 m/min |
Specification of workpieces:
Diameter | φ506-656mm, |
Surface roughness | Ra≤0.3 µm |
Max. weight | 300KG |
Max. length | 2300mm |
Product Features:
- Ra≤0.3 µm, smooth effect
- Polishing material easily exchanged
- High Efficiency
- Enclosed bright protection frame to view easily
- PLC/CNC for easy operation
Packaging Details
1.PE film cover on machine.
2.Carton protection in Plywood case.
3.Or based on your requirements.
Port
Shanghai Port / Nanjing Port / Customer Demand
Technical Service:
1) Design rational process for customers according to their product positioning.
2) Help customers carry out technological transformation on the entire process to improve their production efficiency and capacity.
3) Customize polishing machine configurations and other manufacturing equipment for customers; provide spare parts to equipment users.
4) Help customers test, inspect and analyze new processes, and offer reasonable suggestions and improvement proposals.
5) Improve customer operation on polishing equipment; train their ability to use the equipment and improve their application efficiency.
6) Provide software train for customers and software design of special patterns.
7) Provide processing service for special products.
8) Provide professional designers of technological application to equipment users.
9) Provide technical advice, equipment maintenance and repair services.
After-sales Service:
• Free on-site installation and commissioning. (Customer provides air ticket + accommodation)
• 24-hour service hotline; providing free instruction and answering your questions.
• Life-time maintenance; one-year warranty. After warranty, we provide reasonable prices of spare parts and service.
• Once a year on-site free maintenance. (Customer offers airfare + accommodation, or completed by our local agent)
• Comprehensive and systematic technical training, to ensure your correct operation of the equipment.
