• Model NO.：ZYYX27-190-950
• Customized：Customized
• Advantage：Use Widely
• Condition：New
• Machine Size：About 12*1.5*1.4m
• Delivery Time：About 60days
• Machine Weight：About10t
• Machine Motor：5.5kw
• Certificate：ISO,CE,Soncap
• Machine Color：Made-to-Order
• Brand Name：Zhongyuan
• Forming Type：Cold Roll Forming
• Control System：Mitsubishi PLC
• Hot Sourcing：Automatic Glazed Tile Cold Roll Forming Machine Wi
• Transport Package：1*40gp Container
• Specification：CE SGS BV
• Trademark：Zhongyuan
• Origin：Zhejiang, China
• HS Code：84552210
• Production Capacity：10sets,Month

ItemSpecificationMaterialTypeColor steel sheetThickness(mm)0. 5 -0. 6Yield strength(mpa)235 -345Roller material45#Chrome steelForming speed(m/min)About 1500-2000mm/min or 4-5m/min. For optionStep distanceAdjustable according to requirement (>=250mm)Speed adjusting modeAC FrequencyRoller drive                                               Decelerating motor + Chain driveCutting modeHydraulic cuttingCutter material Cr12 mold steel Length measurement EncoderControl mode Mitsubishi  PLCOperating modeButton +  Mitsubishi  Touch screenMain motor power(kw)5.5KW    (Depend on final design)Hydraulic station power 5.5K W   (Depend on final design)Total power(kw)11KWUncoiler's loading capacityMax. Capacity: 5000kgs
(can be increased to be 10T)Machine`s sizeAbout 12*1.5*1.4m  (Depend on final design)Machine weightAbout 10000kgsComponents of machine:Decoiler1set   Feeding & guiding device1setMain roll forming machine1setPressing device1setHydraulic cutting system1setControlling system1setRun out table 1set   Process flow:
Decoiler -- Feeding & Guiding -- Roll Forming-- Pressing--Hydraulic Cutting - Product to Run Out Table






About us
1. CE, ISO certificate by SGS.
2. Mitsubishi PLC controller and transducer from Japan
3.12moths warranty, lifetime technical support
4. Capacity: 12-15 sets/month
5. Delivery: In only 5-8 weeks for urgent order
6. Company occupies 6650, in which 5650 for workshops
7. Have our own tool center. 12 sets CNC machines.
8. Rollers covered with 0.05mm hard chrome.
9. Customize machines, R&D team with 15 years well-experience in design machine
10. Third party inspection: Bureau Veritas, SGS. Can provide assessment report.
11. Machine original brand: Zhongyuan
12. Set up business relationship with companies in more than 20 countries
