• Model NO.：as the drawing
• Application Range：Aluminum Foils,Plates and Stainless Foils&Plates
• Transport Package：Seaworthy Package
• Specification：as the requirement
• Trademark：FANGLE
• Origin：China
• Production Capacity：50000tons,Year

Basic Info.

Model NO. as the drawing Application Range Aluminum Foils,Plates and Stainless Foils&Plates Transport Package Seaworthy Package Specification as the requirement Trademark FANGLE Origin China Production Capacity 50000tons/Year

Product Description

Performance:

Materail	strength of extension(MPa)	Yield strength(MPa)	ductility(%)	hardness(HB)
ZG310-570	570	310	≥ 17	217-255
35CrMo	≥985	≥835	≥ 12	≥229
35CrMoV	≥1080	≥930	≥ 10	≥240
35NiCrMo	≥830	≥660	≥ 8	≥240
KCP-12	≥1080	≥835	≥ 8	240-260

Chemical material:

Material	C	Si	Mn	Cr	Ni	Mo	V	S,P	illustration
ZG310 -570	0.50	0.60	0.90					<=0.040	Low plasticity and toughness, poor high temperature resistance, Low purchasing cost
35CrMo	0.32 - 0.40	0.17 - 0.37	0.40 - 0.70	0.80 - 1.1		0.15 - 0.25		≤0.035	High strength, toughness and hardenability, General high temperature resistance Low purchasing cost
35CrMoV	0.30 - 0.38	0.17 - 0.37	0.40 - 0.70	1.00 - 1.30		0.20 - 0.30	0.10 - 0.20	≤0.035	Slightly better than 35CrMo, Can meet the general use requirements, Economical purchasing cost
35NiCrMo	0.30 - 0.37	0.60 - 0.90	0.70 - 1.00	0.40 - 0.90	0.60 - 0.90	0.40 - 0.50		<=0.035	High strength and toughness , good high temperature resistance, high purchasing cost
