• Model NO.：QC12K-6X5000mm
• Cutting Thickness(Mm):6：Cutting Lengt(Mm):5000
• Transport Package：Plastic Cover
• Trademark：ZYMT
• Origin：China
• HS Code：8462299000
• Production Capacity：3000 Sets,Year

TypeCutting thickness(mm)Cutting length(mm)Angle range(°)Material strengthTravel timesPowerWeightDimension
L*W*H*(mm)4*2500425001°30'≤450105.538003040*1610*16204*3200432001°30'≤450105.550003840*1610*16204*4000440001°30'≤45085.565004600*1700*17004*6000460001°30'≤45057.5110006460*2100*32006*2500625001°30'≤450107.550003040*1610*16206*3200632001°30'≤45097.560003840*1610*16206*4000640001°30'≤45087.580004620*1750*17006*5000650001°30'≤45067.5105005400*1750*17006*6000660001°30'≤450511165006480*2100*23008*2500825001°30'≤450107.560003040*1700*17008*3200832001°30'≤45087.572003860*1700*17008*4000840001°30'≤45087.588004640*1700*17008*5000850001°30'≤45087.5115005400*2400*20008*6000860001°30'≤450811180006480*2100*235010*25001025001°30'≤45091173003040*1700*170010*32001032001°30'≤45091180003860*1700*170010*40001040001°30'≤450811120004650*2100*200010*60001060002°≤450515240006500*2100*230012*25001225002°≤450918.590003140*2150*200012*32001232002°≤450918.5108003880*2150*200012*40001240002°≤450818.5130004680*2150*200012*50001250002°≤450618.5160005900*2150*200012*60001260002°≤450518.5290006900*2600*270012*80001280002°≤450518.54650009000*3500*350016*25001625002°30'≤450918.5110003140*2150*200016*32001632002°30'≤450818.5130003880*2150*200016*40001640002°30'≤450818.5163004650*2150*220016*50001650002°30'≤450618.5200005900*2600*270016*60001660002°30'≤450522360006900*2700*270020*25002025003°≤450822155003440*2300*250020*32002032003°≤450822180004150*2350*270020*40001040003°≤450522210004850*2350*270025*25002525003°≤450837190003200*2700*290025*32002532003°≤450537230004200*2700*290025*40002540003°≤450537270003850*2700*290030*25003025003°≤450537235003300*2900*290030*32003032003°≤450537275004200*2900*2900

Features:
1:The machine is fitted with CNC controller special for shearing machines.
2:The position of rear stopper is displayed in real-time manner.
3:Multi-step programming function is available and the rear stopper is able for automatic operation and continues positioning, to achieve an automatic adjustment for position of rear stopper.
4:It is provided with counting function for shearing , to display the shearing numbers in a real-time manner ,able for power-failure memory of position of rear stopper, procedures, and parameters.
5:Backgauge with precision ball screw and linear guide, to ensure the positioning precision, so that bring the higher precision processing.

1:Basic standard NC machine with E21s controllerNO.Parts nameBrandBrand locationModel1.Main motorSiemensGermany 2.Bacguage motorJiahuangHangzhou China 3.ElectricsSchneiderFrance 4.Oil cylinderYuhuaMaansh China 5.Seal ringNokJapan 6.Hydraulic valveRexrothGermany 7.PumpHangfaShanghai China 8.ControllerE21Nanjing China 9.BladesJinshanShanghai China 10.Pipe connectorEMBGermany 11.FootswitchKarconSouth Korea 12.Ball screwHiwinTaiwan 13.Controller with moveable armYES14.Front and back protection fenceYES15.Backguage with ball screwYES16.Backguage travel500MM17.Shadow line lightingYES18.Emergency buttonYES
2:  E200S higher level NC controller with servo motor of x-axisNO.Parts nameBrandBrand locationModel1.     Main motor SiemensGermany 2.     Bacguage motorEstunNanjing China 3.     ElectricsSchneiderFrance 4.     Oil cylinderYuhuaMaansh China 5.     Seal ringNokJapan 6.     Hydraulic valveRexrothGermany 7.     PumpHangfaShanghai China 8.     ControllerE200sNanjing China 9.     BladesJinshanShanghai China 10.   Pipe connectorEMBGermany 11.   FootswitchKarconSouth Korea 12.   Ball screwHiwinTaiwan 13.   Guide railHiwinTaiwan 14.   Controller with moveable armYES15.   Front and back protection fenceYES16.   Backguage with ball screwYES17.   Backguage travel600MM18.   Shadow line lightingYES19.   Emergency buttonYES
3:Two axes DAC310 CNC control systemNO.Parts nameBrandBrand locationModel1.     Main motor SiemensGermany 2.     Bacguage motorEstunNanjing ChinaServo motor3.     ElectricsSchneiderFrance 4.     Oil cylinderYuhuaMaansh China 5.     Seal ringNokJapan 6.     Hydraulic valveRexrothGermany 7.     PumpHangfaShanghai China 8.     ControllerDAC310Nanjing China 9.     BladesJinshanShanghai China 10.   Pipe connectorEMBGermany 11.   FootswitchKarconSouth Korea 12.   Ball screwHiwinTaiwan 13.   Guide railHiwinTaiwan 14.   Controller with moveable armYES15.   Front and back protection fenceYES16.   Backguage with ball screwYES17.   Backguage travel600MM18.   Shadow line lightingYES19.   Emergency buttonYES

 Optional controllers
DAC310
Bright LCD 128*64 display
Back gauge control, Gap control, stroke length limitation;
Actual and programmed position visualization, stroke counter;
Programmable up to 100 steps;
Panel-based housing;
Servo control/ unipolar / AC two-speed control;
Mm/inch transmission

E200S
Back gauge control, bus mode control servo system;
Stroke length limitation, double programmable digital output;
Program memory of up to 40 programs, up to 25 steps per program;
One side positioning, retract function;
Mm/inch transmission, Chinese /English transmission;
240*128 pixels LCD display.

E21S
Back gauge control, control for general AC motor, frequency inverter;
Intelligent positioning, double programmable digital output;
Stock counter, program memory of up to 40 programs, up to 25 steps per program;
One side positioning, retract function;
One key backup, restore of parameters;
Mm/inch transmission, Chinese/English transmission;LCD display.

P40
analog or digital outputs for 1-3sreed operation
16 free programmable digital in-/outputs
program memory(1000 sets)
angle control/ gap control/ back gauge
limitation of the cutting length
material of the cutting length
material list for angle and gap control


HT071
regulated power supply for encoder or push pull/o.c.
optical line 12 vdc ±5% 120ma
optoisolated inputs
high luminosity led display having 6 digits plus sign for position
2 digits for cycles and for programs
possibility to save up to 99 programs composed of 20 cycles
each cycle can count 65000 repetitions at maximum
data and programs are saved in a flash memory without floating battery
IP65, polycarbonate, water and abrasion-proof keyboard with tactile sensitivity

Our factory
With a fast speed development since founded in 2001,ZYMT maanshan Middle Asia Machine Tools Manufacture Co.,Ltd, today is placed as a professional manufacture and global supplier of sheet metal working machinery specialized in the production of all the types of hydraulic CNC/NC/Conventional press brakes, hydraulic CNC/NC/Conventional guillotine shear machine s& hydraulic CNC/NC/Conventional swing beam shearing machines.
For its manufacturing operations ZYMT occupy 10,000,000 square meters with a production workshop of 5,000,000 square meters, making it one of the Chinese largest facility for professional sheet metal fabrication machinery.The total workforce at ZYMT is currently numbered at 450 employees and is composed of highly trained and qualified machine operators and assembly technicians supported by a staff of experienced engineers and designers.
All the ZYMT products are manufactured with the Chinese AAA level good standardization and accredited for the ISO9001:2008 and CE certification.In the past years ZYMT has progressed to become a major exporter of sheet metal machineries to the world markets with customers located in all the machine tools consuming countries.ZYMT is currently represented in over 60 countries and regions worldwide through appointed dealers.In the base market of china, we have more than 40 branches in the quality development and service.
Here, with a long and strong engineering experience behind, ZYMT wishes to present itself as a quality-conscious,  professional machinery building company serving the industry.


Our service
1:Established over 100 sales and service outlets in the country's 29 provinces, municipalities and also the establishment of foreign 72 sales points, machine sales, spare parts supply, maintenance, technical advice and a range of services for users at hone and abroad.
2:We have a specialized group in charge of the whole business process.Pre-sales to be a staff, the sales is a friend, and after-sales we are partners.
