• Model NO.：RB series
• Production Capacity：500PCS,Year

Basic Info.

Model NO. RB series Production Capacity 500PCS/Year

Product Description

ZP28-M20
AXLE THREAD ROLLING MACHEINE
TECHNICAL PARAMETERS
Rolling spiline rangeMax. DiameterAxial feedmm20
Max. ModuleAxial feedmm2.5
Rolling die rangeMax. Outer diametermm175
Aperturemm54
Max. Widthmm80
Max. Center distance btw. Main axismm196
Main axis rotationr. P. M. 42.53.68.87
Main axis inclination ± 6°
Center height mm900
Gross powerKW4.2
Dimensions(L× W× H)mm1176× 1160× 1200
Packing dimensions (L× W× H)mm1650× 1300× 1600
Weight Kg1500

ZPA28-15
CIRCLE DIE
THREAD ROLLING MACHEINE
TECHNICAL PARAMETERS
MAX. Rolling pressure KN150
Rolling spiline range Max. DiameterRadial feedmm60
Axial feedmm45
Max. ModuleRadial feedmm4
Axial feedmm5
Rolling die rangeMax. Outer diametermm178
Aperturemm54
Max. Widthmm120
Max. Center distance btw. Main axismm240
Main axis rotationr. P. M. 28.35.45.56
Main axis inclination ± 5°
Feed travelmm0-12
Center height mm900
Gross powerKW8
Dimensions(L× W× H)mm1500× 1440× 1400
Packing dimensions (L× W× H)mm1800× 1750× 1900
Weight Kg2500

ZPA28-20
CIRCLE DIE
THREAD ROLLING MACHEINE
TECHNICAL PARAMETERS
MAX. Rolling pressureKN200
Rolling spiline range Max. DiameterRadial feedmm70
Axial feedmm45
Max. ModuleRadial feedmm5
Axial feedmm6
Rolling die rangeMax. Outer diametermm178
Aperturemm54
Max. Widthmm140
Max. Center distance btw. Main axismm240
Main axis rotationr. P. M. 28.35.45.56.
Main axis inclination ± 5°
Feed travelmm0-12
Center height mm900
Gross powerKW11
Dimensions(L× W× H)mm1550× 1460× 1600
Packing dimensions (L× W× H)mm1800× 1750× 1900
Weight Kg2800

ZPA28-25
CIRCLE DIE
THREAD ROLLING MACHEINE
TECHNICAL PARAMETERS
MAX. Rolling pressure KN250
Rolling spiline range
Max. DiameterRadial feedmm80
Axial feedmm80
Max. ModuleRadial feedmm6
Axial feedmm8
Rolling die range
Max. Outer diametermm220
Aperturemm75
Max. Widthmm160
Max. Center distance btw. Main axismm300
Main axis rotationr. P. M. 16.21.27.37.46.62
Main axis inclination ± 5°
Feed travelmm0-16
Center height mm950
Gross powerKW14.2
Dimensions(L× W× H)mm1580× 1600× 1650
Packing dimensions (L× W× H)mm2250× 2000× 1900
Weight Kg3560


We have all kinds of cicle die thread rolling machine.

We have service center in India, our engineer in the India all the year round.
So we can provide you the best service and best price.
We have many cutomers in India use this machine.
Hope to cooperate with you.
