CNC Thread Rolling Machine From Nina

Anshan Ying Yat Trade Co., Ltd.
  • Name：Thread Rolling Machine
  • Other Name：Screw Rolling Machine
  • Overall Dimension：1600×1680×1650
  • Weight：4080
  • Suitable Material：Carbon Steel, Ally Steel,Non-Ferro Metal
  • Packing Size：2250×2000×1900

Base Info

  • Model NO.：HM-ST08
  • Feed Stroke：0-16
  • After-Sales Service ?：Yes
  • Guarantee Period：12 Months
  • Condition：New
  • Transport Package：Exported Packing
  • Specification：GB
  • Trademark：HM-ST08
  • Origin：China
  • Production Capacity：Custom-Made

Description

Main Parameters of Thread Rolling MachineMax rolling-forceKN320Rrolled thread rangeMax diameterRadial feedmm90Axial feedmm50Max thread pitchRadial feedmm6Axial feedmm8Range of thread rolling wheelMax outer diametermm220Hole diametermm75Max widthmm180Max center distance of spindlemm300Spindle rotationr.p.m.16.21.27.37.46.62Spindle inclination angle ±5°Feed strokemm0-16Machine center heightmm950Machine total powerKW18.2Overall dimension (LXWXH)mm1600×1680×1650Packing box size (LXWXH)mm2250×2000×1900WeightKg4080




Features:
1. Machine body is made of high quality casting iron, resin-boned sand process. Six rotation speed is adjustable, which enhanced the machine body stiff.
2. It is suitable for the carbon steel, alloy steel and other non-ferro metals.
