C Z Quick Change Metal Roofing Roll Forming Machine

Botou Golden Integrity Roll Forming Machinery Co., Ltd.
  • Suitable Material to Produce：Galvanized Steel Strip
  • Thickness of Raw Material：1.0-3.0mm,or as Your Request
  • Main Power of Machine：11.5kw
  • Power of Cutting：6kw,5.5kw,3kw
  • Material of Cutter：Cr12 with Heat Treatment
  • Material of Roller：45 Steel,with Chrome Coating

Base Info

  • Model NO.：80-300
  • Splint Thickness：20mm
  • Color of Machine：Blue or as Your Request
  • Driving of Machine：Chain Driving
  • Sizes of Chain：1.2 Inch
  • Transport Package：Covered with Plastic Films
  • Specification：ISO9001
  • Trademark：ZD OR OEM
  • Origin：China
  • HS Code：84552210
  • Production Capacity：30sets,Month

Description

Item:Specification:Notes:



1.Information of coilSuitable material:colored armor plate with the bending intensity of 250 MPA

Width:Depend on different design
Thickness:1.0-3.0mm
2.Production specificationDetailed as the file
Length:Any length,Encoder to measure length3.Power requirement:Main power:11kwWith inventorCutter power:4kw
4.Forming Speed:8-10m/minNot including cutting
5.Manual de-coiler:Loading:2-3tons
Inner diameter 508mmType:Passive type




6.Machine specification:Structure:350 I beam welded
Roll stations:14roll stationsSplint thickness:20mmDiameter of shaft:80mm(solid)Sizes of chain:1 inchType of cutting:Hydraulic cuttingMaterial of cutter:CR12Material of rollersCarbon steel with heat-treatment,
Sizes of machine:11*1.3*1.5meters
