• Model NO.：CHV850
• Customized：Customized
• Advantage：Good Quality and High Precision
• Condition：New
• X Axis Travel：850mm
• Y Axis Travel：550mm
• Z Axis Travel：580mm
• Distance From Table Surface to Spindl：120-700mm
• Table Dimensions：1020*550mm
• Spindle：8000rpm(10000-30000 Optional)
• Machine Tool Diameter：100,150
• Power Consumption：20kVA
• Floor Space：2940*2180*2350
• Machine Weight：6200kg
• Transport Package：Wooden Case
• Specification：CE,SGS,ISO9001
• Trademark：LEAD
• Origin：Suzhou City, Jiangsu Province, China
• Production Capacity：60 Sets,Month

CHV-850TRAVEL
LINEAR GUIDE WAYX axis travelmm850Y axis travelmm550Z axis travelmm580Distance from table surface to spindle nosemm120~700TABLE

table areamm1020x550Max. load of tablekgs600T-slotmm4 x 18 x 125SPINDLE
8000RPM StandardSpindle taper
BT-40BT-40HSK-50ESpindle speedrpm8000/1000010000/12000/1500024000/30000Transmission type
BeltDirect DriveBuilt-in Spindle motorkw5.5/7.55.5/7.515/17Spindle cooling
Oil coolerFEED RATE

Rapid traverse(X,Y)m/min30Rapid traverse(Z)m/min20Cutting feed ratemm/min1~100003 Axes motor output(X,Y,Z)kw1.8/1.8/2.5A.T.C.

Magazine type
CarouselArmTool magazine capacitypcs16(20)24Max. tool diametermm100/15080/150Max. tool lengthmm250250Max. tool weightkgs77Tool selectiontypeFixed typeRandomOTHER

Power consumptionKVA20Floor space(LxWxH)mm2940x2180x2350Machine weightkgs6200
