• Model NO.：Infrared Powder Coating Oven
• Transport Package：Wooden Carton
• Specification：Electric Batch Powder Booth
• Trademark：COLO
• Origin：China
• Production Capacity：300sets,Month

Basic Info.

Model NO. Infrared Powder Coating Oven Transport Package Wooden Carton Specification Electric Batch Powder Booth Trademark COLO Origin China Production Capacity 300sets/Month

Product Description

Δ Infrared Powder Coating Burn Off  Oven
Basically, infrared heat energy is emitted by a hot body and transferred in straight lines until it makes contact with another body when the heat is absorbed by the latter causing it to rise in temperature.

Δ Advantage of radiant heating
It produces a rapid rise in object temperature. As the temperature of the heating source is increased, so the proportion of heat transferred by radiation as opposed to convection increases appreciably. The amount of heat energy radiated from any source depends upon its area, its temperature and its emissivity.

Medium temperature radiation offers the most effective source of radiant heat for curing thermosetting powder. Usually the emitter panels are gas-fired giving a panel surface temperature of 850-950oC, or alternatively sheathed electric panels of a surface temperature of 750-850oC. The workpiece is maintained at about 30cm from the emitter panel surface with a minimum distance of 15cm.

The color of the powder is an important consideration light colors can reflect (depending on powder composition) proportionately more infra-red radiation and do not heat up as quickly as the darker colors. This means that each and every powder must be evaluated to determine the optimum curing conditions.
As radiant heat tracks in straight lines, coated articles of intricate design, or having sections shielded from the radiation source cannot be processed using this method. Ideally infra-red radiation is used for simple workpieces such as relatively flat surfaces

Features
1,COLO powder coating ovens are designed to safely and efficiently cure previously applied powder coating media
2, Our energy-efficient designs save fuel and get to temperature quickly.
3,Standard and custom sizes range from small Lab units to large heavy equipment ovens and conveyorized curing systems.
4, All our powder coating ovens feature premium 100mm thick insulated wall and roof panels,excellent for keeping temperatures.
5. Deigned with trolley with racking system, the trolley can design according to your metalworks,in order to
conveneint for parts hanging and transport
6.Control panel :With temperature  alarm ,could set baking time and tempreture ,when baking
time arrive ,stop automaticly .

Why Choose Us
1.   More than 10 years manufacturing experience in whole powder coating line.
2.   Afford one stop service:reseach ,development design ,production,abroad installation.
3.   Customized as you want.
4.   Competitive price.we are factory.Design, produced ,installed all by ourself,save cost.
5.   One year of warranty period and life long technical support.
6.   Market share in Global: about 90%, is a leading factory in this filed.

We Sincerely looking forward to do business with you,and will welcome you visit our factory!
