• Model NO.：Drywall Ceiling Profiles Roll Forming Machine
• Transport Package：Suitable for Sea Transport
• Specification：1*40GP Container
• Trademark：Zhongyuan
• Origin：Zhejiang, China
• HS Code：84552210
• Production Capacity：10sets,Month

Basic Info.

Model NO. Drywall Ceiling Profiles Roll Forming Machine Transport Package Suitable for Sea Transport Specification 1*40GP Container Trademark Zhongyuan Origin Zhejiang, China HS Code 84552210 Production Capacity 10sets/Month

Product Description

Automatic Easy Operation Drywall Ceiling Profiles Roll Forming Machine With Good Quality


Machine's Overvew



Technical Data

Suitable material	PPGI,PPGL Steel Coils, with 0.7mm thickness
Yield Strength	Q235Mpa
Working speed	About 25m/min
Main motor power	5.5 Kw(Depend on final design)
Hydraulic station power	5.5Kw(Depend on final design)
Cutter material	Cr12 mould steel with quench treatment
Roller Material	No. 45 forged steel with 0.05mm thickness chrome
Material of shaft	High quality 45# steel, Dia. is 72mm
Controlling system	Mitsubishi PLC & Converter
Length measurement	Encoder(Nemico)
Operation mode	Botton+Mitsubishi Touch Screen
Total weight	About 6000KGS(Depends on final design)
Machine Size	About 6*1.2*1.4m (Depends on final design)

Machine Components

1	Manual decoiler	1 pc (Capacity:3 tons)
2	Guiding Equipment	1 set
3	Punching device	1 set
4	Roll Forming Equipment	1 set
5	Post-Cutting&Folding Equipment	1 set
6	Hydraulic Station	1 pc
7	PLC Control Panel	1 pc
8	Supporter Table	1 set (Two pieces, 1.5m/piece)
9	Tool Box	1 pc
