• Model NO.：KLS25-220-530
• Customized：Customized
• Advantage：Work Flexible
• Condition：New
• Dimension：1700*1100*1200mm
• Weight：800kgs
• Motor Power：1.5kw
• Voltage：380V,50Hz,3pH
• Effective Width：220-530mm
• Material Width：290-600mm
• Material Thickness：0.5-0.8mm
• After-Sales：Engineers Available to Service Machinery Overseas
• Delivery Time：Delivery Immediately After The Machine Is Assemble
• Forming Steps：6steps
• Transport Package：Nude in Container
• Trademark：XHH
• Origin：Xiamen of China
• HS Code：84552290
• Production Capacity：20 Sets,Month

Basic Info.

Model NO. KLS25-220-530 Customized Customized Advantage Work Flexible Condition New Dimension 1700*1100*1200mm Weight 800kgs Motor Power 1.5kw Voltage 380V/50Hz/3pH Effective Width 220-530mm Material Width 290-600mm Material Thickness 0.5-0.8mm After-Sales Engineers Available to Service Machinery Overseas Delivery Time Delivery Immediately After The Machine Is Assemble Forming Steps 6steps Transport Package Nude in Container Trademark XHH Origin Xiamen of China HS Code 84552290 Production Capacity 20 Sets/Month

Product Description

KLS25-220-530 Mini Type Standing Seam Roof Panel Machine, Panel Forming Machine and Metal Roof Machine:

Main Technic Data:
Type: KLS25-220-530;
Size: 1700*1100*1200mm(L*W*H);
Weight: 800KGS;
Motor Power: 1.5KW;
Effective Width: 220mm, 530mm;
Material Width: 290mm, 600mm;
Material Thickness: 0.5-0.8mm;
Materail: Galvanized sheet, Al-Mg-Mn sheet, Colored prepainted sheet.
Usage: Making standing seam roofing panels for buildings.

1.	Dimension	1700*1100*1200mm
2.	Weight	800KGS
3.	Motor Power	1.5KW
4.	Power for hydraulic forming cutter	0.75KW
5.	Voltage	380V/50HZ/3PH
6.	Forming Steps	6 steps
7.	Forming Speed	6-8m/min
8.	Thickness for Steel	0.5-0.8mm
9.	Height of Roofing	25mm
10.	Effective Width for Roofing	220-530mm
