• Model NO.：QC12Y 10X6050
• Trademark：ALUKE
• Origin：China
• HS Code：846239
• Production Capacity：120 Sets,Month

NO.ItemCountUnitRemark1Max cuttable thickness≤10mm
2Max cuttable width6050mm
3Tensile strength of steel plate to be cut≤450N/mm2
4Shear angle2 °30′/
5Throat Depth150mm
6Max distance of backgauge1000mm
7Strokes8n/min
8Distance between upright columns6265mm
9Length of the blade6150mm
10Distance between workbench and ground800mm
11Primary Motorpower22KW
rotation rate1440r/min
12Gear pumpmodelNBT5-G63F/
flow63L/min
pressure31.5Mpa
13Power380V/50Hz/3Phase/(According to customer requirements changes)
Main Parts
1. Hydraulic system      Omega (Sino-American)
2. Packing nnit                    Japan NOK
3.Oil Pump                         HONGTING in Shanghai
4.Electric Component          SIEMENZ


Feature or characteristic.
1. Assistant Tooling Set on work table, make tooling adjustment easier
2. Rolling material support make operation easier
3.Indication by indicator is provided for adjustment of blade clearance, for a handy and prompt adjustment.
4.The adoption of four-side edge shearing blade prolongs the service life of blade.
5. Alignment device with lighting and control device for shearing stroke are set, with a handy and prompt adjustment.
6. The rear stopper is fitted with electric adjustment and manual adjustment devices, and digital display device is available for display of size of stopper and times of shearing.
