Hydraulic Guillotine Cutting Machine for Aluminium Sheet

Shanghai Aluke Equipment Co., Ltd.
  • Cutting Thickness：12mm
  • Cutthing Width：6000 mm
  • Working Material：Metal Sheet
  • Power Supply：380V or Option
  • Transport Package：Steel Tray
  • Specification：International Standard

Base Info

  • Model NO.：QC12Y 12X6000
  • Trademark：ALUKE
  • Origin：China
  • HS Code：846239
  • Production Capacity：120 Sets,Month

Description

No.NameAmountUnitRemark1Max. thickness of plate12mm
2Max. width of plate6000mm
3Tensile strength450N/mm2
4Shear angle2°30′

6Max back gauge range800-1000mm
9
Gear PumpModelNT3-G63F

10Flow63L/min
11Pressure31.5MPa
12Main motor power18.5KW
13Voltage380V/50Hz/3Phase(According to customer requirements changes)



Main Parts
1. Hydraulic system      Omega (Sino-American)
2. Packing nnit                    Japan NOK
3.Oil Pump                         HONGTING in Shanghai
4.Electric Component          SIEMENZ


Feature or characteristic.
1. Assistant Tooling Set on work table, make tooling adjustment easier
2. Rolling material support make operation easier
3.Indication by indicator is provided for adjustment of blade clearance, for a handy and prompt adjustment.
4.The adoption of four-side edge shearing blade prolongs the service life of blade.
5. Alignment device with lighting and control device for shearing stroke are set, with a handy and prompt adjustment.
6. The rear stopper is fitted with electric adjustment and manual adjustment devices, and digital display device is available for display of size of stopper and times of shearing.
