Bolt Maker
HARBIN RAINBOW TECHNOLOGY CO., LTD.- Type：Forging Operation
- Forging Forming Method：Mold Forging
- Power Source：Hydraulic Pressure
- Feature：Automation
- Certification：ISO9001, CE
- Warranty：12 Months
Base Info
- Model NO.：SRH-64S,SRH-64L,SRH-84L,SRH104S,SRH-104L,SRH-134L
- Customized：Customized
- Advantage：Use Widely
- Condition：New
- Color：Blue
- Transport Package：Wooden Packages
- Specification：4 stations forging machine
- Trademark：SRH-64S,SRH-64L,SRH-84L,SRH104S,SRH-104L,SRH-134L
- Origin：CHINA
- Production Capacity：100 sets,year
Description
FORGING STATIONNo. 4 4 4 4 4 4 4 FORGING FORCE kgs 40,000 50,000 60,000 70,000 80,000 80,000 120,000 MAX. CUT-OFF DIA. mm φ8 φ8 φ10 φ10 φ12 φ12 φ15 MAX. CUT-OFF LENGTH mm 96 125 100 160 150 200 220 OUTPUT pcs/min 140 - 210 60 - 180 120 - 180 70 - 160 60 - 140 60 - 135 70 - 110 MAX. P.K.O LENGTH mm 12 12 16 15 15 26 25 DIE KICK OUT LENGTH mm 52 52 115 80 162 102 230 MAIN MOTOR kw 12 15 19 20 20 30 30 CUT-OFF QUILL mm φ 30*45L φ 30*45L φ 35*50L φ 35*50L φ 45*59L φ 45*59L φ 63*69L PUNCH SIZE mm φ 40*90L φ 40*110L φ 45*115L φ 50*130L φ 53*115L φ 53*115L φ 60*130L DIE SIZE mm φ 50*110L φ 50*130L φ 60*120L φ 60*150L φ 75*135L φ 75*185L φ 86*190L DIE PITCH mm 60 60 80 80 92 92 110 APPROX. WEIGHT kgs 10,000 12,000 14,500 17,000 18,000 21,000 26,000 DIA. OF PRODUCTION mm 3- 6 3 - 6 5 - 8 5 - 8 6 - 10 6 - 10 8 - 13 LENGTH OF PRODUCTION mm 10 - 75 10 - 100 15 - 77 12 - 130 12 - 102 15 - 152 20 - 152
