• Model NO.：RB
• Transport Package：Wooden Box
• Specification：CE
• Trademark：Rainbow
• Origin：China
• Production Capacity：300sets,Year

 Item8451Wire sizeΦ1.0- Φ4.5mm(IronΦ1.0- 6.0mm)2Feeding lengthMaxΦ80mm3Outside diameter±0.01~±9999.994Wire feed speed0-60m/min5Cam setting value±0.10º~±359.90º6Cam rotation speed1~60RPM7Motor wire feed5.5kw8Motor cam5.5kw9Motor axis1.5kw10Power AC380V±10%V50HZ11Dimensions1320x730x1720mm12Weight2200KG
1. Bendable φ 6mm wire (low carbon steel).
2. The maximum bending angle of 190 ° .
3. The maximum bending radius R20mm.
4. Maximum bending cycles unlimited.
5. Standard feed length 1000mm.
6. The maximum angle of 360 ° .
7. The maximum feed speed 700mm / sec.
8. Precision: Bending accuracy ± 1 ° , feeding accuracy ± 0.05mm, rotation accuracy ± 0.05 ° .
9. The machine body can store 10, 000 kinds, but comes with a USB interface, so that customers easy to use.
10. Comes with diagnostic function test abnormalities will alarm.
11. The drive is fully pneumatic.
12. The three-axis, using AC servo motor.
13. Electrical Capacity: 3-phase 380V, 3.0kVA, with power self-protection (circuit breaker Mitsubishi) to prevent data loss.
14. Compressed air consumption: 60L / MIN, 0.6MPa.
15. XY Z coordinate input and motion data input comes with a graphical display.
16. The device is available M20 expansion screws, two each front and rear.
17. The process can provide five times suspended. Party B to provide free access to the system program update service.
18. Last corner shortest 25MM.





19. With automatic loading and unloading.


For anything of the machine, please feel free to contact me.
Doris
