5 Axis 3D 300A 400A Plasma and Flame CNC Steel Metal Pipe Tube Profile Cutter Cutting Machine
Shanghai Tayor Heavy Industry (Group) Co., Ltd.- Customized：Customized
- Layout：Coaxial
- Cutting Material：Copper, Carbon Steel, Iron, Aluminum, Metal Alloy, Stainless Steel
- Automatic Grade：Automatic
- Power Source：Electric
- Cutting Mode：Plasma Cutting
Base Info
- Model NO.：CNCXG
- Cutting Method：Plasma, Flame, Laser
- 3D Bevel Cutting：Available
- Cutting Thickness：1-80mm
- Cutting Speed：50-9000mm,Min
- Cutting Pipe Diameter：40-1600mm
- Cutting Length：6m, 12m
- Transport Package：Plywood Case and Tray
- Specification：CE, ISO9001: 2008, GB
- Trademark：TAYOR
- Origin：China
- HS Code：8456901000
- Production Capacity：1000 Sets,Year
Description
Hypertherm Model Air Plasma Oxygen Plasma HPR130XD HPR260XD HPR400XD HPR800XD Data PowerMax1650 Max200 HSD130 Mild steel Production(piercing) 12 mm 25 mm 25 mm 16mm 32 mm 38mm 38mm Quality 19 mm 25 mm 25 mm 25 mm 32 mm 50 mm 50mm Cut off 44 mm 50 mm 35 mm 38 mm 64 mm 80 mm 80mm Stainless steel Production(piercing) 12 mm 25 mm 20 mm 16 mm 32 mm 40 mm 75mm Cut off 44 mm 50 mm 25 mm 25 mm 50 mm 80 mm 160mm Aluminum Production(piercing) 12 mm 25 mm 20 mm 16 mm 25 mm 40mm 75mm Cut off 44 mm 50 mm 25 mm 25 mm 50 mm 80 mm 160mm Cutting speed (12mm mild steel) 1447mm/min 2159mm/min 2200 mm/min 2200 mm/min 3850 mm/min 3850 mm/min 3850 mm/min TD Air Plasma Air Plasma ULTRACUT100 ULTRACUT200 ULTRACUT200 Data A40 A60 A80 A120 AUTOCUT200 AUTOCUT300 Max Piercing 6mm 10 12 mm 18mm 25 mm 35 mm 15mm 25 mm 40 mm Best cutting 4mm 8 10mm 16 mm 25 mm 35 mm 15mm 25 mm 35 mm Max cut off 15mm 20 30 mm 35mm 50 mm 75 mm 35mm 50 mm 75 mm Cutting current 20-40A 20-60A 80A 100A 200A 300A 10-100A 10-200A 10-300A Power 380V 6.3KW 380V 9 KW 380V 12 KW 380V 15.4 KW 380V 32 KW 380V 48 KW 380V 18KW 380V 36KW 380V 54KW
