• Model NO.：HH-350,9
• Max.Inlet Wire Dia.：8mm
• Block Dia.：500mm
• Max. Number of Block：21
• Certification：REACH, RoHS, ISO
• Condition：New
• Wire Size：2.6-3.5mm
• Wire Finished Diameter：1.0-2.76mm
• Max Dies No.：9
• Fix Speed Capastan Diameter：350mm
• Spool Bobbin Size：Sn500 Sn630 Option
• Max Loading Capacity：250kg(Sn500) or 500kg(Sn630)
• Transport Package：Wood Package
• Specification：CE ISO SGS
• Trademark：HOOHA
• Origin：Dongguan
• HS Code：8463102000
• Production Capacity：5 Sets,Month

 ModelZLT350/9Control systemdigital buttonpower controldual inverterwire inlet dia2.6-3.5mmwire finished diameter1.0-2.76mmmax wire speed 1200m/minmax dies No.9transmission typegear drivemechanical elongation25%+16.7%drawing capastantungsten carbide
 construction of the machine body casting+steel plate welding and annealingcapastan diameterMax 350mmfix speed capastan diameter350mmspool bobbin sizeSN500 SN630 optionbobbin loading unloading typedual sfaft conetraversing unitAC reducer motor and timing beltmain motorAC55kw(6P)spool motorAC11kwrevise systemrevise system automatic control of take up by PIDtension controltension control buffer rod with air cylinder and rocket arm
 max loading capacity250kg(SN500) or 500kg(SN630)lubrication typelubrication by full immersionlubrication capacity100L/minbrake disk type brakelubrication type for bearing pump enforce oilannealing control3 poles DC current outputannealing capacity150KVAannealing voltagemax 65Vannealing current2500A
 power source380V/50/60Hztotal power77kw+150KVAsteam consymption 10-12m³/h, 0.2-0.3Mpa with 9kw steam generatorcooling water consumption15-20m³/h 0.2-0.25MPaair consumption20-30m³/h 0.4-0.6MPamachine dimension14*3.5*4Mgross weight7000kgTeam of HOOHA serviceNameeducationPositionMainly responsible for projectSpecializing in project Industry working history
( year )zanyang XiecollegeGeneral EngineerThe total project design and planning power cable machine15xioahua HucollegeVis general engineerThe total project design and planning net cable,data cable machine10Chnaghong ChengcollegeEngineerDrawings and after-sales serviceTeflon,Optical fiber cable machine25xiuwu ChencollegeGeneral EngineerThe total project design and planning copper drawing machine15lixin YuancollegeEngineerThe project design and planning coppwer wire making technical16zhenghai Qiucollegecable engineerAfter servicecable making and cable factory management servie15jinxin LiucollegeMarketing engineerAfter serviceelectrical engineer7xingguo TangHigh schoolElectrical engineerAfter serviceelectrical engineer10changqiang LiHigh schoolMaintain engineerAfter servicemachina maintain and install service10haipin LiUniversityEngineering director Marketing and salesproject consulting 8sen YangUniversityEngineering translatorMarketing and salesproject consulting 5
