• Model NO.：ZX6350A
• Production Capacity：300 Sets,Mnth

ItemZX6350ZAZX6350ASpindle taperISO40(V) ISO40(H)ISO40(V) ISO40(H)Diameter of quill100mm100mmDistance from  spindle to table90-370mm90-370mmDistance from Horizontal spindle to table0-280mm0-280mmDistance from spindle to column200-700mm200-700mmSpindle speeds(8 step)60-1500 r.p.m(V) 40-1300 r.p.m(H)(8 step)115-1750 r.p.m(V) 40-1300 r.p.m(H)Spindle travel120mm120mmFeeding of quill(3 step)0.15 0.08 0.25 -Max.drilling capacity of auto-feedingø12 -Head movement±45°±45°Table size1250x320mm1250x320mmTable travel(Horizontal/Cross/Vertical)600/300/280mm600/300/280mmFeeding range of longitudinal.cross travel 22-550mm/min 22-550mm/min X,Y axis rapid feed speed1080mm/min1080mm/minZ axis rapid feed speed590mm/min590mm/minZ axis motor power750W750WMax weight of workpiece200kg200kgT-slot number/width/distance3/14mm/70mm3/14mm/70mmMilling head moving(vertical)Dovetail axisDovetail axisCross slide wayRectangular axisRectangular axislongitudinal slider wayDovetail axisDovetail axisHorse power for main motor1.5kw(V) 2.2kw(H)0.85/1.5kw(V) 2.2kw(H)X,Y axis driving motor 750W750WOverall dimension1780x1500x2100mm1780x1500x2100mmPacking size1680x1600x2250mm1680x1600x2250mm 2300x1600x2250mm2300x1600x2250mmN.W/G.W1450/1550kg(2900/3100kg)1450/1550kg(2900/3100kg)
