Tongda11 Filter Electroplating Chemical Filter with Pump for Electroplating Factory
Junan Tongda Electronic Equipment Factory- After-sales Service：Yes
- Voltage：220V
- Automatic Grade：Automatic
- Warranty：1 Year
- Certification：CE
- Control System：Manual, Remote, PLC
Base Info
- Model NO.：TD 11
- OEM Service：Accept
- Material of Tank：PP, PVC, Ss
- Heating Model：Electronic, Steam, Hot Water
- Equipment Type：Manual, Semi-Automatic, Full-Automatic
- Application：Surface Treatment
- Packaging Details：1.Non-Standard 2. Wood CTN
- Plating Style：Hang Plating , Barrel Plating
- Thickness of Tank：15 mm, Customized
- Auxiliary Equipmen：Rectifiers, Filters, Chiller, Pipe, Air Blower,etc
- Condition：New
- Electroplating Plating：G Available: Zinc,Copper ,Nickel,Tin,Chrome,Sliver
- Available for：Machine Part,Nail,Faucet,Bolt,Customization
- Type：PP and Ss
- Transport Package：Twine Film
- Specification：Customized
- Trademark：TONGDA
- Origin：China
- HS Code：8543300090
- Production Capacity：1500 Set,Month
Description
Filter Element's number :
(Size x Number )
Filter: The filter chamber is constructed of all polypropylene with bottom inlet and bottom discharge. We have mold filter and pump body by ourselves. The Discharge is o-ring sealed. A powder coated support plate provides added strength. Chambers have side mounted inlet/outlet connections for closer mounting to the tank.
Stainless steel eyebolts with hand wheels hold the powder coated steel cover in place. An air release valve is provided. A stainless steel pressure gauge is also included.
Base is polypropylene with stainless steel channel structure and polypropylene feet.
Injection Tank: The injection tank is polypropylene construction. It's used to facilitate pre filtration, addition of carbon (if required), and solution make-up. These are sized to store the complete capacity of the filter chamber during changing of the media or maintenance. Inlet/outlet connections are located at the end of the mounting base.
Piping, Valves and Connections: Piping, valves, and connections are all hard pipe polypropylene or pvc as request.
Filter media selected for the application is placed between the rigid polypropylene discs. Ten (10) micron cellulose is standard.
In fact,for better communication,may I add your other contact information?
FAQ:
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A:it is according to quantity.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
