• Model NO.：ZYYX
• Customized：Customized
• Advantage：Use Widely
• Condition：New
• Certificate：CE
• Machine Size：7*1.2*1.5m
• Machine Weight：About 5.5t
• Main Motor：5.5kw
• Delivery：About 50 Days
• Operation Language：English or as Per Client`S Required
• Rollers Material：No.45 Forged Steel, Plated with Hard Chrom
• Cutter Material：Cr12 Mould Steel Being Quenched Treatment
• Cutting Style：Cut to Length
• Controlling System：Mitsubishi PLC & Converter
• Transport Package：1*40gp Container
• Specification：CE SGS BV ISO Soncap
• Trademark：zhongyuan
• Origin：China
• HS Code：84552210
• Production Capacity：15sets,Month

ItemSpecificationMaterialTypepre-painted galvanized steel sheet Thickness(mm)0. 4 -0. 6Yield strength(mpa)235 -345Roller material45#Chrome steelShaft diameter (mm)about 55Forming speed(m/min)About 15Step distanceAdjustable according to requirement Speed adjusting modeAC FrequencyRoller drive                                               Decelerating motor + Chain driveCutting modeHydraulic cuttingCutter material Cr12 mold steel Length measurement EncoderControl mode Mitsubishi  PLCOperating modeButton +  Mitsubishi  Touch screenMain motor power(kw)5.5KW    (Depend on final design)Hydraulic station power 5.5K W   (Depend on final design)Total power(kw)11KWUncoiler's loading capacityMax. Capacity: 3000kgsMachine`s sizeAbout 7*1.2*1.5m  (Depend on final design)Machine weightAbout 5500kgs

Feeding & guiding device1setMain roll forming machine1setPressing device1setHydraulic cutting system1setControlling system1setRun out table 1set

Components spec.:
1.  Decoiler Max. Capacity: 3000kgs
2.  Hydraulic station power: About 5.5Kw (Depend on final design)
3.  Control system: Mitsubishi PLC with touch screen
4.  Cutting length: Cut-to-length


Process flow:
Decoiler -- Feeding & Guiding -- Roll Forming-- Pressing--Hydraulic Cutting - Product to Run Out Table





Please feel free to contact us for more information!
