• Model NO.：as the drawing
• Application Range：Piercing Mill
• Transport Package：Woodern Pallet
• Specification：Export package
• Trademark：FANGLE
• Origin：China
• Production Capacity：10000 Tons,Year

Basic Info.

Model NO. as the drawing Application Range Piercing Mill Transport Package Woodern Pallet Specification Export package Trademark FANGLE Origin China Production Capacity 10000 Tons/Year

Product Description

Guide disc is a guide device of the piercing mill . The function of the guide disc is to form the closed pass of steel pipe.The piercing mill with guide disc is widely used in the seamless steel tube production.Our products have high temperature resistance, not easy to bond, high wear resistance, high heat crack resistance.Good toughness, hardness and other characteristics.

We work out a new material centrifugal casting guide discs for seamless steel pipes piercing mill,which has a good performance and long service life.



Material Requirements:

Technical Description of Material:

Material	Description	Hardness
SG12	Pearlitic spheroidal graphite cast Iron (sand cast)	290-310HB

Chemical Composition:

C	Si	Mn	P	S	Cr	Ni	Mo	Mg
2.9-3.6	1.4-2.6	0.4-1.0	Max. 0.15	Max 0.03	0.1-0.6	1.5-3.0	0-0.8	Min 0.04
