6 Tons Automatic Hydraulic Steel Uncoiler Machines
Xiamen Xinhonghua Machinery Co., Ltd.- Condition：New
- Certification：SGS
- Customized：Customized
- Material：Metal
- Application：Metal Cutting Machine, Metal Straightening Machinery, Metal Spinning Machinery, Metal forging Machinery, Metal Drawing Machinery
- Type：Uncoiler
Base Info
- Model NO.：6MT
- Weight：1500kgs
- Motor Power：4kw
- Hydraulic Power：2.2kw
- Voltage：380V,50Hz,3pH
- Max.Loading：6metric Ton
- Max.Width for Sheet：1250mm
- Transport Package：Standard Package for Export
- Specification：SGS
- Trademark：XHH
- Origin：Xiamen Fujian China
- HS Code：8455229090
- Production Capacity：20sets,Month
Description
Basic Info.
Model NO. 6MT Weight 1500kgs Motor Power 4kw Hydraulic Power 2.2kw Voltage 380V/50Hz/3pH Max.Loading 6metric Ton Max.Width for Sheet 1250mm Transport Package Standard Package for Export Specification SGS Trademark XHH Origin Xiamen Fujian China HS Code 8455229090 Production Capacity 20sets/MonthProduct Description
Specifications
Hydralic uncoiler
(1) Hydraulic System;
(2) Feeding Device;
(3) Controlling System for automatically expand and decrease;.
7 Tons Hydraulic Uncoiler
Main Accessories:
(1) Main Machine;
(2) Hydraulic System;
(3) Feeding Device;
(4) Controlling System for automatically expand and decrease;
Main Technic Data
Size | 2500*1750*1700mm |
Weight | 1500KGS |
Hydraulic Motor Power | 2.2KW |
Hydraulic Power for feeding device | 0.75KW |
Voltage | 380V/50HZ/3PH |
Inner Diameter | 450-550mm |
Out Diameter | Max.1500mm |
Max. Loading | 6tons |
Max. Width for Sheet | 1250mm |
