Copper Wire Drawing Machine with Annealer
HOOHA Co., LIMITED- Type：LW Pulley Type Metal Drawing Machine
- Usage：Wire, Prestressed Steel Wire
- Metal Material：Copper
- Outlet Diameter：0.1-1.2mm
- Max.Inlet Wire Dia.：8mm
- Block Dia.：500mm
Base Info
- Model NO.：24DHT
- Max. Number of Block：21
- Certification：REACH, RoHS, ISO
- Condition：New
- Certificate：ISO
- Motor：Germany-Siemens
- Bearing：Japan-NSK
- Inverter：Siemens
- Electric Element：Siemens and Omron
- Control Box：International Standard
- Transport Package：Wood Package
- Specification：CE ISO SGS
- Trademark：HOOHA
- Origin：Dongguan
- HS Code：8479400000
- Production Capacity：3 Sets,Month
Description
wire drawing machine with annealingModel 17DHT SMD205T 24DHT control system digital readout button power control dual inverter wire inlet diameter 0.75-1.6mm 0.95-1.65mm 0.5-1.2mm wire finished diameter 0.2-0.5mm 0.15-0.4mm 0.1-0.32mm max wire speed 2000m/min 2000m/min 2000m/min max dies NO. 17(18) 24 24 mechanical elongation 15%+8.7% 15%+13% 13%+8.7% construction of the machine body casting+steel plate welded and annealed drawing capstan ceramic coated capstan diameter 242mm 242mm 242mm fix speed capstan diameter 206mm drawing/take up motor AC55kw/AC11kw spool bobbin size 300*215*270mm transmission type import advanced flat belt drive bobbin loading unloading type expansion shaft or single shaft cone main motor 15kw 15kw 11kw spooler motor 4kw tension adjustment weight type tension pulley fix system automatic control of take up by PID max loading capacity 50kg lubrication capacity 50L/min lubrication type spraying brake magnetic brake lubrication type for bearing without oil annealing control 3 poles DC current output annealing capacity 30 KVA 21 or 30 KVA 21KVA annealing voltage 0-57V annealing current 400A 400A 300A total power 19kw+30KVA 19kw+30KVA 15kw+30KVA power source 380V,50/60HZ Steam consumption 6-9kg/h 0.2-0.3MPa coiling water consumption 4-8m³/h 0.2-0.25MPa air consumption 15-25m³/h 0.4-0.6Mpa dimensions 3*2.5*2.3M weight 3000kg
Afetr service
1).Delivery dates: 45 days
2).Payment: TT or L/C
3).Packing: Wood packing and PE plastic packing ensure the goods safety on the transportation.
4). Install and training service: 2 professional engineers who has over 5 years overseas install and cable manufacture training experience.
5) after service phone number online
Contact information
Add:No.Beice District, Humen Town, Dongguan City, Guangdong Province,China
If the machine is not suitable for your wire spec., please contact me.
Why us?
We are the cable equipment manufacturer
Professional engineer,long term to research and development for to cable equipment .
High frequency capacity manufacturer machine is provide .Guarantee the machine all weather running .
Our machine use the international qualified brand,like Siemens ,Omron,NSK,LG etc.
Install and training service.Guarantee overseas install and cable manufacture training experience.
Technical support and spare parts service.
Professional and Strong Manufacture and Sells TeamTeam of HOOHA service Name education Position Mainly responsible for project Specializing in project Industry working history ( year ) zanyang Xie college General Engineer The total project design and planning power cable machine 15 xioahua Hu college Vis general engineer The total project design and planning net cable,data cable machine 10 Chnaghong Cheng college Engineer Drawings and after-sales service Teflon,Optical fiber cable machine 25 xiuwu Chen college General Engineer The total project design and planning copper drawing machine 15 lixin Yuan college Engineer The project design and planning coppwer wire making technical 16 zhenghai Qiu college cable engineer After service cable making and cable factory management servie 15 jinxin Liu college Marketing engineer After service electrical engineer 7 xingguo Tang High school Electrical engineer After service electrical engineer 10 changqiang Li High school Maintain engineer After service machina maintain and install service 10 haipin Li University Engineering director Marketing and sales project consulting 8 sen Yang University Engineering translator Marketing and sales project consulting 5
