Good Sealing Protect Penetration Function Traffic Sign Self-Piercing Riveting Machine

RSM Machinery Co.,Ltd.
  • After-sales Service：Online Video Support
  • Automatic Grade：Semi-Automatic
  • Power Supply：Pneumatic
  • Warranty：2 Years
  • Certification：CE
  • Deep Throat：800mm

Base Info

  • Model NO.：TCEB10-800-02
  • Force：100kn
  • Total Stroke：100mm
  • Type：Vertical
  • Number of Head：2
  • Boost Stroke：10mm
  • Transport Package：Standard Export Wooden Box
  • Specification：500X1200X1450mm
  • Trademark：OEM
  • Origin：Shanghai, China

Description

ModelTCEB10-800-02Number of heads2Use rivet3.3mmPressure of gas-liquid booster cylinder100KNTotal stroke100mmBoost stroke10mmDistance between upper and lower dies60mmC-type plate opening size200mmThroat depth of type C plate800mmCenter distance between two riveters40-120 mmOverall size1500X1200X1450mmNet weight1200KG
Good Sealing Protect Penetration Function Traffic Sign Self-Piercing Riveting MachineGood Sealing Protect Penetration Function Traffic Sign Self-Piercing Riveting MachineGood Sealing Protect Penetration Function Traffic Sign Self-Piercing Riveting MachineGood Sealing Protect Penetration Function Traffic Sign Self-Piercing Riveting MachineGood Sealing Protect Penetration Function Traffic Sign Self-Piercing Riveting MachineGood Sealing Protect Penetration Function Traffic Sign Self-Piercing Riveting MachineGood Sealing Protect Penetration Function Traffic Sign Self-Piercing Riveting MachineGood Sealing Protect Penetration Function Traffic Sign Self-Piercing Riveting Machine
FAQ:

1.Why choose SPR connection?
The process of SPR connection is different with that of welding. It includes positioning, clamping and automatic feeding of rivet. Then the rivet will pierce through the upper material and form plastic deformation in the bottom material, and finish shaping. This is an easy and rapid process.
2.Do you provide custom service?
Yes.According to the throat size you need.
3.What is this drive method?
This is pneumatic SPR machine, we also supply hydraulic SPR machine.
4.How can I improve the productivity of this machine?
You can choose 2 riveting heads SPR machine.
5.What materials can be connected
Aluminum,Deep drawing steels,High strength steels and so on.
