EDM Wire Cutting Machine Model Dk7763b
Suzhou Baoma Numerical Control Equipment Co., Ltd.- Casting：Ht250
- Delivery Time：Within One Month After Getting Your Down Payment
- Transport Package：Standard Plywood Packing
- Specification：CE, ISO9001, ISO14001
- Trademark：BAOMA
- Origin：Jiangsu Suzhou
Base Info
- Model NO.：Dk7763b
- HS Code：3205361231
- Production Capacity：300 Sets,Year
Description
CNC Wire Cut EDM [DK7763B]
Unit
DK7763B
Worktable size (L× W)
mm
660×1100
Table travel(X× Y)
mm
800× 630
Max. workpiece thickness
mm
500
Max. taper angle/plate thickness
degree/mm
± 0° /100
Max. machining speed
mm² /min
120
Precision
Octagon
mm
≤ 0.015
taper
mm
≤ 0.04
Max. working current
A
6
Roughness, three cutting
μ m
≤ 1.5
Wire diameter
mm
0.15~0.2
Wire travelling speed
m/min
5~11
Load of table
Kg
400
Working solution
working solution BM-2/BM-4 or Saponification Liquid
Working reservoir capacity
L
56
Power supply
3N-380V/50Hz
Power consumption
KVA
3
Wire guide frame
Adjustable
Machine dimensions(L× W× H)
mm
2200× 1750× 1950
Package dimensions(L× W× H)
mm
2460× 1960× 2000
Machine weight
Kg
1700
Controller type
BMW-3000
