Rolling Shutter Slats Roll Forming Doors Making Industrial Machine Jm85

Xiamen Xinhonghua Machinery Co., Ltd.
  • Type：Hydraulic Machine
  • Forging Forming Method：Mold Forging
  • Power Source：Hydraulic Pressure
  • Feature：Automation
  • Certification：SGS
  • Warranty：12 Months

Base Info

  • Model NO.：JM85
  • Customized：Customized
  • Advantage：Work Flexible
  • Condition：New
  • Forming Steps：14steps
  • Motor Power：4kw
  • Hydraulic Motor Power：2.2kw
  • After-Sales Service Provided：Engineers Available to Service Machinery Overseas
  • Delivery Time：Delivery Immediately After The Machine Isassembled
  • Roller Material：Gcr15
  • Shaft Material：40cr
  • Cutting Material：Cr12MOV
  • PLC：Schneider
  • Tolerance：±2mm
  • Transport Package：Standard Package for Export
  • Specification：SGS
  • Trademark：XHH
  • Origin：Xiamen, China
  • HS Code：8455229090

Description

Size4000*900*1400mmWeight2500KGSMotor Power4kwHydraulic Motor Power2.2KWForming Steps14stepsProcessing Speed8-12m/minVoltage220V/60HZ/3PHEffective Width85mmMaterial Width136mmMaterial Thickness0.8-1.0mmCut-off systemHydraulic cutting deviceMaterial of principal axishigh grade 45# forged steelMaterial of roller45#steel with hard chrome platingMaterial of bladeCr12 mould steel with quenched treatment 60-62°CMaterial for frame of machineFine welded structural steelSprocket wheel45 steel high-frequencies quenchMaterial for producing roofingnormal colored painted and galvanized sheets with strength 245, 345MPA;Rolling Shutter Slats Roll Forming Doors Making Industrial Machine Jm85
Rolling Shutter Slats Roll Forming Doors Making Industrial Machine Jm85
Rolling Shutter Slats Roll Forming Doors Making Industrial Machine Jm85
