DC Inverter Air Plasma Cutting Tool Cut-40 Quality Precision
Shenzhen Exlentech Welding Equipments Co., Ltd.- Customized：Customized
- Layout：Horizontal
- Cutting Material：Carbon Steel, Iron, Metal Alloy
- Automatic Grade：Manual
- Power Source：Electric
- Cutting Mode：Plasma Cutting
Base Info
- Model NO.：CUT-40
- Name：Plasma Cutting Machine
- Mosfet：12PCS
- Diodes：12PCS
- Capacitor：4PCS
- Transport Package：Carton
- Specification：371x153x232mm
- Trademark：As required
- Origin：Shenzhen China
- HS Code：84569010
- Production Capacity：30000PCS,Month
Description
Basic Info.
Model NO. CUT-40 Name Plasma Cutting Machine Mosfet 12PCS Diodes 12PCS Capacitor 4PCS Transport Package Carton Specification 371x153x232mm Trademark As required Origin Shenzhen China HS Code 84569010 Production Capacity 30000PCS/MonthProduct Description
Plasma cutting machine product Characteristics:*Adjustable cutting current,satisfy different requirement of material,thickness,cutting speed.esthetic cutting area.
*Plasma cutting machine can be used to cut carbon steel,stainless steel,galvanized steel,copper,aluminum etc.
*Buildin default phase protection,over and low voltage protection,over heat protection,and low pressure of compressed air protection etc,make the machine work reliably.
*Plasma cutting machine easy to operate, flat,smooth cutting area.
| Model | LGK-40 |
| Input power Voltage Frequency(V,Hz): | AC220(single phase)±15%,50/60 |
| Rated input power capacity(KVA): | 4.8 |
| No-load voltage(V): | 230 |
| Output current range.(A): | 10-40 |
| Rated output voltage(V): | 96 |
| Duty cycle (%)(25ºC): | 60 |
| No-load loss(w): | 40 |
| Arc-starting: | touch |
| Efficiency(%): | 85 |
| Power factor (COSφ): | 0.93 |
| Insulation class: | F |
| Weight(KG): | 9 |
| Overall dimension(mm): | 365×138×238 |
| Case protection degree : | IP21S |
| Air compressor displacement(S): | 0.17 |
| Max cutting thickness(mm): | 12 |
