• Model NO.：DX 840 860 900 1050
• Customized：Customized
• Advantage：Use Widely
• Condition：New
• Name：Trapezoidal Sheet Forming Machine
• Thickness：0.2-1.0mm
• Material Expand Width：1000mm 1200mm 1250mm
• Roller Material：High Grade No. 45 Forged Steel with 0.05mm Hard CH
• Shaft Material：High Grade No. 45 Carbon Wrought Steel
• Cutting Blade：Cr12 Mould Steel with Quenched Treatment
• Medium Plate：14 Mm or as Your Requirement
• Main Frame：300 H,U Steel
• Controlling System：Famous PLC Computer Control
• Appearance Size：5.8*1.3*1.0m
• Transport Package：Water-Proof Packaging, Covered with Plastic Film
• Specification：DX840 900 1050
• Trademark：DIXIN
• Origin：Botou Hebei China
• HS Code：845522
• Production Capacity：20 Set Per Month

Basic Info.

Model NO. DX 840 860 900 1050 Customized Customized Advantage Use Widely Condition New Name Trapezoidal Sheet Forming Machine Thickness 0.2-1.0mm Material Expand Width 1000mm 1200mm 1250mm Roller Material High Grade No. 45 Forged Steel with 0.05mm Hard CH Shaft Material High Grade No. 45 Carbon Wrought Steel Cutting Blade Cr12 Mould Steel with Quenched Treatment Medium Plate 14 Mm or as Your Requirement Main Frame 300 H/U Steel Controlling System Famous PLC Computer Control Appearance Size 5.8*1.3*1.0m Transport Package Water-Proof Packaging, Covered with Plastic Film Specification DX840 900 1050 Trademark DIXIN Origin Botou Hebei China HS Code 845522 Production Capacity 20 Set Per Month

Product Description

1050 Color Steel Tile Roll Forming Machine for Export

Components of whole set roll forming machinery:

1. De-coiler

2. Shearing Device

3. Forming System

4. Cutting Device

5. Run-out table

6. Electrical System and Control system

Technical Parameters

1. De-coiler
Manual Un-coiler
Width of raw material: 1250mm
Max Capacity: 8000kgs
Max out diameter of coil: 1600mm
Inner diameter of coil: 500-600mm
Manual feed with brake


2. Shearing Device
Shearing way: Manual
The material of blade: Cr12 with Heat treatment HRC60-62

4. Cutting device
Oil pump station 1set
Motor power of Oil pump station: 4kw
Forced air cooling device available
Cutting mould: 1set
Material of blade: CR12 with heat treatment HRC60-62
Pressure of cutting: 15tons

5. Run-out Table
Frame: Angle bar or steel tube welded
Length: 3m
Quantity: 1 pc

6. Electrical System
PLC and HMI touch Screen (Taiwan Delta or Siemens)
Automatic length measurement
Automatic quantity measurement
Length measurement: Rotary Encoder
Over current protection for control system, aviation plugs
Cutting off type: Paused to cut, moving automatically after cutting.
Power: 380V 60Hz


We also can design and manufacture as per your request!

material spec	colored steel sheet,galvanized steel sheet,aluminium sheet
thickness of coil sheet	0.3-0.8 mm
material expand width	1000mm 1200mm 1250mm
roller material	high grade NO. 45 forged steel with 0.05mm hard chrome plating
shaft material	high grade NO. 45 carbon wrought steel
cutting blade	Cr12 mould steel with quenched treatment
diameter of shaft	70mm or as your requirement,the largest diameter is 95 mm
medium plate	14 mm or as your requirement
main frame	300 H/U steel
form,ing steps	11 rows
productivity	10-12m/min
main motor power	3 KW
hydraulic station power	3 KW
hydraulic pressure	10-12MPa
controlling system	famous PLC computer control
material of  cutting table	Cr 12 mould steel with quenched treatment
appearance size	5.8*1.3*1.0m
leak frame load bearing	2.6 tons
hydraulic oil	36# hydraulic oil
Electric tension	380V 50 Hz 3 Phase or as your requirements

If you want to know more information about China Steel Machine Trapezoidal Sheet Forming Machine, please contact to me now!
If you are interested in the roll forming machine,please feel free to ask me:
