Mechanical Three Roller Rolling Machine (W11 8X2500)
Shanghai Aluke Equipment Co., Ltd.- Usage：Metal Roll
- Metal Material：Steel
- Certification：ISO, CE
- Condition：New
- Thickness:8mm：Width:2500mm
- Transport Package：Steel Tray
Base Info
- Model NO.：W11 8X2500
- Specification：International Standard
- Trademark：ALUKE
- Origin：China
- HS Code：846229
- Production Capacity：100 Sets, Month
Description
| Specs | Unit | W11_8×2500/3200 |
| Type | Mechanical symmetrical | |
| Max bending width | mm | 2500/3200 |
| Working length of the rollers | mm | 2550/3300 |
| Max thickness of plate | mm | 8 |
| Plate yield limit | Mpa | 245 |
| The diameter of up roller | mm | Ø240/Ø260 |
| The diameter of down roller | mm | Ø180/Ø220 |
| Center distance of the two rollers | mm | 300/320 |
| Min dia when full loading | mm | 550/600 |
| Rolling speed | m/min | About 4 |
| Power of main motor | KW | 7.5/11 |
| Overall Size | mm | 4150*1100*1100mm/4950*1300*1300mm(L*W*H) |
| Power | 380V/50Hz/3Phase/(According to customer requirements changes) | |
