• Model NO.：RDL-36
• Max.Inlet Wire Dia.：36mm
• Block Dia.：1400mm
• Max. Number of Block：1
• Certification：ISO
• Condition：New
• Model：Vertical
• Transport Package：Into Contaier
• Specification：depends on different model
• Trademark：Rainbow
• Origin：China
• Production Capacity：200sets,Year

Basic Info.

Model NO. RDL-36 Max.Inlet Wire Dia. 36mm Block Dia. 1400mm Max. Number of Block 1 Certification ISO Condition New Model Vertical Transport Package Into Contaier Specification depends on different model Trademark Rainbow Origin China Production Capacity 200sets/Year

Product Description

Machine Description

RDL36 inverted wire drawing machine parameters and configuration
1. The main motor: 75 kw - 6 p speed regulation of frequency conversion motor
2. The frequency converter: 75 kw (vector control)
3. The drum:  1400 mm diameter, material: chilled cast iron, the surface hardness HRC55 - HRC56
4. Level 3 speed reducer: V14 type four axis (hard tooth face)

Take-up wire
1. Take-up motor: 2.2 kw - 6 p general motors
2. Type inverter: 2.2 kw (vector control)
3. The reducer: WPO135 type
4. The discharging machine: 1.5 kw - 6 p

Hydraulic clamping device
1. Hydraulic cylinder: 100 * 180  three groups
2. : nip  150 * 250 alloy nylon material 2 x 3 groups

 Specification
1. Max drawing speed: 45 m/min
2. Max incoming diameter :  36mm
3. Incoming strength: 1000 Mpa For high carbon steel
4. The biggest reducing: 200 s standard of high carbon steel
5. The largest storage line: 2.5 T
6. Compaction method: three groups of six rounds of hydraulic clamping
7.Drum diameter: 1400mm
8.Motor: 75KW


Company Profile

Our company comes from China National Machinery Import and Export Corp. Harbin branch. By many years market development and experience accumulation,now we have became the biggest Chinese fastener equipment dealer and turnkey consultants of fasteners manufacturing project for abroad customers.

  We are supplying high quality and reliable machines for the entire fastener industry with our professional and timely after sale service,our main products include wire drawing machine,Bolt Maker, Nut Maker, Part Former, Heading Machine, Thread Rolling Machine and Mesh Belt Furnace.

  With our business reputation and professionalism, our company has experienced a significant growth in business during the recent years and we invested in some fastener equipment manufacturers and built our own bolt maker,mesh belt furnace and zinc plating line factories.We do these factories' foreign market developing and have received highly praises from a lot of customers.

  We have established reputation in countries such as India, US, Europe and Southeast Asia where we have core customer bases. Meanwhile, we are well respected by the domestic factories and the customers in the mechanical and electrical business.
