Big Size 1300*2500mm Laser Cutter Machine for Metal
Perfect Laser (Wuhan) Co., Ltd.- After-sales Service：Online Support
- Warranty：2 Year Warranty for Laser Source
- Working Area：3000mmx1500mm 620X620mm
- Motor：Japan Servo Motor
- Max Cutting Depth：1-8mm
- Input Power：16kw
Base Info
- Model NO.：PE-M500-2513,PE-M700-2513
- Cooling System：Water Cooling
- Power：500,700W
- Table Repeat Positioning Accuracy：0.02mm
- Max. Cutting Speed：20-50mm,S
- Minimum Line Width：0.4 Mm
- Warranty Period：12 Months
- Transport Package：Wooden Case
- Specification：ISO, CE, SGS, TUV
- Trademark：Perfect Laser
- Origin：China
- HS Code：8456100090
- Production Capacity：5000 Sets,Year
Description
Standard Configuration
1. Advanced Germany Technology: Ensure most high tech in the world.
2. Advanced Laser Optical System: Ensure Excellent Laser Beam Quality Double-Xenon-lamp technology, can strongly improve the laser power and laser beam quality.
3. Laser Path Pre-view & Pre-position Function: Laser beam is in-visible by adopting "Red Light Pointer" Realize the laser path pre-view and Pre-position function.
4. Pre-view and pre-run function: Simulate the laser cutting path Pre-run the cutting path in advance Ensure finding the accurate cutting position.
5. Unique Mirrors and Lens Cooling Technology: All mirrors and?lens is cooled by water, Takes the mirror heat during working, Prolong its' lifetime, Save future operation cost.
6. Red light pointer: As the laser beam is in-visible, We adopt red light pointer to indicate the real position of the laser beam, Make cutting more accurate.
7. Laser Bridge:Adopt USA imported Metal Laser Cavity & Laser Xenon lamp (Double lamp Technology) Strongly improve the power and laser beam quality.
8. High Precision Laser Cutting Head: Excellent Laser Beam, Strong Laser Power Have 3 laser beam adjusting screw to adjust the laser path easily.
9. Professional Saw-tooth Type Cutting Table: Heavy Loading Can move from left to right, up to down Lifting range is 300mm Suitable for different height of work-pieces.
10. Drawer Design: Convenient to collect work-pieces. Also can collect dust and metal scrap.
11. Japanese Panasonic Servo motor and Driver: Extreme precise positioning, Make moving positioning mechanism operate smoothly, Reliably and free of maintenance.
12. Taiwan Made Ball Screw Rod: Diameter 50mm ball screw rod, High accuracy linear running guide rail, Improve the precision and accuracy of the machine.
13. Taiwan Linear Guide Rail: High speed with Lower noise volume, High accuracy and long life span.
14. Industry Computer: CPU is Intel Core i3, DDR3 is 4G SSD is 250G.
15. Professional Laser Cutting Software: Adopt CNC 2012 latest version, with powerful editing function, Friendly interface, Easy to Use. Supports DXF, PLT, G-Code and many graphs.
16. Foot Switch: Press it for cutting easily.
17. 5P Powerful Water Chiller: Increase the stability of cutting power, Support water flow testing, Makes the cutting power more stable. Avoid material cut un-completely. Enhance the working efficiency.
Company Profile
Perfect Laser (Wuhan) Co., Ltd. is a professional manufacturer of industrial laser equipments, in China "Optics Valley" - Wuhan City. Since 1995, Perfect Laser focused on the development and production of various types of laser machinery and CNC equipments.
Our products include laser engraving machine, laser cutting machine, laser marking machine, laser welding machine, die board laser cutting machine, 3D laser engraving machine, cnc router, plasma cutter, dot peen marking machine, inkjet printer, CNC letter bending machine, etc.. More than 20 series, 300 types, certificated by CE, ISO9001:2000, have exported to more than 180 countries.
Our machines are featured by high precision, low energy consumption, automatic processing, little environmental pollution, which play an important role in more and more fields, such as industry, electronics, hardware, advertising, furniture, telecommunication, jewelry, food, clothing, shoes,etc.
