• Model NO.：YX65-300-400-500
• Customized：Customized
• Advantage：Work Flexible
• Condition：New
• Roll Forming Machine：Roofing Forming Machine
• Size：6000*1800*1700mm
• Weight：7000kgs
• Motor Power：7.5kw*2 Sets
• Hydraulic Power：2.2kw
• Forming Steps：13
• Effective Width：300mm,400mm,500mm
• Material Width：470mm,575mm,680mm
• Working Speed：8-14m,Min
• Voltage：380V,50Hz,3pH
• Transport Package：Standard Package for Export
• Specification：YX65-300-400-500
• Trademark：XHH
• Origin：Xiamen of China
• HS Code：84552290
• Production Capacity：10-15 Sets,Month

Basic Info.

Model NO. YX65-300-400-500 Customized Customized Advantage Work Flexible Condition New Roll Forming Machine Roofing Forming Machine Size 6000*1800*1700mm Weight 7000kgs Motor Power 7.5kw*2 Sets Hydraulic Power 2.2kw Forming Steps 13 Effective Width 300mm,400mm,500mm Material Width 470mm,575mm,680mm Working Speed 8-14m/Min Voltage 380V/50Hz/3pH Transport Package Standard Package for Export Specification YX65-300-400-500 Trademark XHH Origin Xiamen of China HS Code 84552290 Production Capacity 10-15 Sets/Month

Product Description

YX65-300-400-500 Standing Seam Roofing Machine, Rolling Forming Machine, Metal Roofing Machine:

Main Accessories:
A. Main roof forming machine;
B. 5 tons manual decoiler;
C. Hydraulic system;
D. PLC computer controlling system with touch screen;
E. Hydraulic forming cutter;
F. Protetive Cover;
G. Operational manual.

1.	Size	6500*1600*1400mm
2.	Weight	6500KGS
3.	Motor Power	5.5KW*2 sets
4.	Hydraulic Power	2.2KW
5.	Voltage	220V/60HZ
6.	Forming Steps	13
7.	Forming Speed	8-14m/min
8.	Effective Width	300mm, 400mm, 500mm
9.	Material of Width	470mm, 575mm, 680mm
10.	Thickness  for Aluminum sheets:	0.6-1.0mm
11.	Thickness for Colored Prepainted and Galvanized  Sheet	0.6-0.8mm
12.	Material for All Rollers	high grade no. 45 forged steel, plated hard chrome on the surface of rollers
