• Model NO.：MR-2000
• HS Code：9024102000
• Production Capacity：100 Sets,Month

Eyepiece10X wide field plan eyepiece and field of view number is Φ22mm, the eyepiece interface is Ф30mmInfinity plan achromatic objectivesMR-2000(Equipped bright field objective)PL L10X/0.25  working distance:20.2 mmPL L20X/0.40  working distance:8.80 mmPL L50X/0.70  working distance:3.68 mmPL L100X/0.85(dry)  working distance:0.40 mmMR-2000B(Equipped with dark / bright field objective)PL L5X/0.12   working distance:9.70 mmPL L10X/0.25   working distance:9.30 mmPL L20X/0.40   working distance:7.23mmPL L50X/0.70   working distance:2.50 mmEyepiece tubeHinged binocular tube, with an observation angle of 45°, and a pupil distance of 53-75mmFocusing systemCoaxial coarse/fine focus, with tension adjustable and up stop minimum division of fine focusing is 2μm.NosepieceQuintuple (Backward ball bearing inner locating)StageMechanical stage overall size: 242mmX200mm and moving range : 30mmX30mm.Rotundity and rotatable stage size: maximal measurement is Ф130mm and minimal clear aperture is less then Ф12mm.Illumination systemMR-20006V30W halogen and brightness enable control.MR-2000B12V50W halogen and brightness enable control.Integrated field diaphragm , aperture diaphragm and puller type polarizer.Equipped with frosted glass and yellow ,green and blue filters
Packaging and shipping
Packaging: Standard export package, wooden case
Delivery: 3 days upon receipt of payment, depend on order quantity

Company Information:
Laizhou LaiHua Testing Instrument Factory was founded in 2010,which specializes in the manufacture of hardness testers  and metallographic equipments for metaland nonmetal materials. Besides, we can also design special, large-scale dedicated machines according to the requirements of customers.
