• Model NO.：PX2500C
• HS Code：84798110
• Production Capacity：100set

Basic Info.

Model NO. PX2500C HS Code 84798110 Production Capacity 100set

Product Description

PX2500C semi automatic winding machine is used to produce big size spiral wound gasket. The maximum gasket size is more than 3000mm.
It use PLC to control spiral wound gasket size and spot welding distance.


STYLE	PX2500C Semi-automatic horizontal winder
Producing ability	SWG with or without IR
SWG thickness	4.5mm (also suitable for 3.2mm,6.4mm and 7.2mm after changing roller parts, V shape winding or W shape winding for option)
Automatic function	PLC size controlling, semi-Automatic spot welding
Maximum gasket OD	2500mm
Minimum gasket ID	300mm
Total power	8kw
Spindle motor power	0.75kw
welder power	6kw
Power supply	380V/220V for option, 3 phases
linear speed	0-800mm/s
Air compressor	0.6-0.8 MPA
Frequency Converter	2.2G
PLC	xinjie
Machine measurement	3400*2600*980mm
Machine net weight	550kg
