• Model NO.：YLSK-2D-406
• Origin：Dongguan
• HS Code：8463300000
• Production Capacity：300 Sets,Year

Basic Info.

Model NO. YLSK-2D-406 Origin Dongguan HS Code 8463300000 Production Capacity 300 Sets/Year

Product Description

 PRODUCT DESCRIPTION

YLSK-2D-406 WIRE BENDING MACHINE.
The configuration uses fully imported high-precision high-speed servo motors, reducers, with a stable and durable production speed that is more than 30% higher than similar domestic counterparts.
The production process can achieve no change in the angle at different speed folding angles, and the production stability is better.
Bearings, guide rails, gears and other important components are imported, which guarantees quality and durable and reliable equipment.
High precision, can be used for wire forming products within the wire diameter range, the error is reduced to 0.1 mm.


TECHNICAL PARAMETERS

Model	YLSK-2D-06
(mm) Wire.diameter	Ø2.0~ø6.0
Axis number	4 axis
Servo motor of wire feed (KW)	2.7
Cutter Servo Motor (KW)	1.0
Lifting Servo Motor (KW)	1.0
Bending Servo Motor (KW)	1.0
Wire feeding Rollers	3 Pairs
Max.Wire Feed Instruction Value	10000.00mm
Min.Wire Feed Instruction Value	0.01mm
Maximum Feeding Length	Unlimited
(KG)Machine weight Kg	950
Overall dimensions LXWL	2100*800*1550
Power	380V.AC.50HZ



FAQ
1. Q: Can you customize the machine for the customer?
  A: Yes,we can.We also provide OEM for customer,if you need customize service,please contact us.

2. Q: What is the Min.Order?
  A:  One set.

3. Q: What is the payment term
  A: The payment term is 30% deposit as PO confirmation ,and 70% after the shipment.We also accept other payment term.

 Q: What is the delivery time?
  A: Normally the delivery time of the machine is 30 days after receiving deposit.But it depends on machine model.Some of
      them could be shipped within 10 days.

5. Q: What is the guarantee period of the machine?
  A: The guarantee period is one year from the date of B/L.
