100kn Pressure Easy Loading and Unloading Pneumatic Spr Equipment

RSM Machinery Co.,Ltd.
  • After-sales Service：Online Video Support
  • Automatic Grade：Semi-Automatic
  • Power Supply：Pneumatic
  • Warranty：2 Years
  • Certification：CE
  • Deep Throat：800mm

Base Info

  • Model NO.：TCEB10-800-02
  • Pressure：50kn
  • Power：4kw
  • Type：Vertical
  • Number of Head：1
  • Transport Package：Standard Export Wooden Box
  • Specification：680*1600*1310mm
  • Trademark：OEM
  • Origin：Shanghai, China

Description

ModelTCEB05-80TCEB05-500TCEB05-1000TCEB05-1500TCEB05-1800TCEB05-2000TCEB05-2400TypeHandheldVerticalControl MethodHandle SwitchFoot SwitchForce50KNWork Pressure(Mpa)31.5Throat Depth(mm)8050010001500180020002400Size(mm)180*65*510680*958*1210680*1800*1510700*2250*1580730*2480*1650750*2680*1780780*2980*1840Balance DeviceSpring Balancer/Motor(KW)4Electronic Control SystemYes
100kn Pressure Easy Loading and Unloading Pneumatic Spr Equipment100kn Pressure Easy Loading and Unloading Pneumatic Spr Equipment100kn Pressure Easy Loading and Unloading Pneumatic Spr Equipment100kn Pressure Easy Loading and Unloading Pneumatic Spr Equipment100kn Pressure Easy Loading and Unloading Pneumatic Spr Equipment100kn Pressure Easy Loading and Unloading Pneumatic Spr Equipment100kn Pressure Easy Loading and Unloading Pneumatic Spr Equipment100kn Pressure Easy Loading and Unloading Pneumatic Spr Equipment
FAQ:

1.Why choose SPR connection?
The process of SPR connection is different with that of welding. It includes positioning, clamping and automatic feeding of rivet. Then the rivet will pierce through the upper material and form plastic deformation in the bottom material, and finish shaping. This is an easy and rapid process.
2.Do you provide custom service?
Yes.According to the throat size you need.
3.What is this drive method?
This is pneumatic SPR machine, we also supply hydraulic SPR machine.
4.How can I improve the productivity of this machine?
You can choose 2 riveting heads SPR machine.
5.What materials can be connected
Aluminum,Deep drawing steels,High strength steels and so on.
