• Model NO.：According to Customers′ Drawings
• Material：Alloy
• Application：Metal Spinning Machinery, Metal Processing Machinery Parts, Metal forging Machinery
• Surface Process：Multi-Option
• OEM：Available
• Designing：Available
• Transport Package：Carton
• Specification：According to the drawings of customers
• Trademark：ZHD
• Origin：Wuhan, China
• HS Code：8401200000
• Production Capacity：5000PCS,Year

Basic Info.

Model NO. According to Customers′ Drawings Material Alloy Application Metal Spinning Machinery, Metal Processing Machinery Parts, Metal forging Machinery Surface Process Multi-Option OEM Available Designing Available Transport Package Carton Specification According to the drawings of customers Trademark ZHD Origin Wuhan, China HS Code 8401200000 Production Capacity 5000PCS/Year

Product Description

Note: This product is just a sample part we once machined according to a customer's drawing, and the price shown on this page is not the real price.

Our procedure for customizing parts for you is as follows:


1. Customer provides 2D or 3D drawings;
2. We quote the prices according to your drawings(we can also design the parts according to your specific requirements);
3. Orders are confirmed by both parties;
4. We start to put your parts into machining;
5. We package and deliver the parts the customer;

Description of This Part

Material:
BG08#, alumina material

Workpiece Requirements:
Good appearance and oxidation

Material properties
BG08 aluminum:
Main Composition: Mn10~1.5, Cu0.1~1.0, Si 0.1~0.5, Ti0.1~0.2, Fe0.2~0.6, Mg1.0~2.5, Zn2.0 ~ 4.0 AL

Advantages:
It is mainly used in products with medium strength requirements and similar performance to 6063. Excellent property of black oxidation, easy to cast, and stable machinability, etc.

Disadvantages:
The color is dark when making color oxidation, and there will be spots when the oxidation is not well controlled, which is relatively difficult to form compared with ADC12

Remark:
The product is developed by our company that is based on the properties between BG01 aluminum and BG04 aluminum, which meets requirement of mechanical properties of general products and has high-quality oxidation. At the same time, it has good castability. It is widely used for handles, aiming tools and general parts in construction industry.

Machining Characteristics:
1.Mold designing and manufacturing.
2.Die-casting molding of products, and stock is left out to the positions with precision requirement for machining.
3. Fitting parts and parts with accuracy requirements are CNC machined to ensure that roundness is within 0.01mm, concentricity is within 0.015mm, and the inner circle tolerance value is + 0.018mm.

Surface Treatment
Spray 120# fine sand + black oxidation treatment to meet the requirements of environmental protection
