Hydraulic Press Brake Machine Wc67y 125/3200 with CE standard
Wmt Cnc Industrial Co., Ltd.- Customized：Customized
- Layout：Horizontal
- Cutting Material：Carbon Steel, Iron, Stainless Steel
- Automatic Grade：Semi-Automatic
- Power Source：Hydraulic Pressure
- Cutting Mode：Wire Cutting
Base Info
- Model NO.：WC67Y 125,3200
- Length of Worktable：3200mm
- RAM Stroke：130mm
- Nominal Pressure：1250kn
- Motor Power：7.5kw
- Transport Package：Standard Ply-Wood Case
- Specification：CE SGS ISO9001
- Trademark：WMT
- Origin：Chizhou, Anhui, China
- HS Code：8462399000
- Production Capacity：20sets,Month
Description
MODELNominal pressure Length of worktable Distance between uprights Ram stroke Throat depth Motor power kn mm mm mm mm kw WC67Y-40/2000 400 2000 1590 100 200 5.5 WC67Y-40/2200 400 2200 1590 100 200 5.5 WC67Y-40/2500 400 2500 2090 100 200 5.5 WC67Y-50/2500 500 2500 1900 120 250 5.5 WC67Y-50/3200 500 3200 2600 120 250 5.5 WC67Y-63/2500 630 2500 2050 100 250 5.5 WC67Y-63/3200 630 3200 2600 100 250 5.5 WC67Y-80/3200 800 3200 2600 100 250 5.5 WC67Y-80/4000 800 4000 3200 100 250 7.5 WC67Y-100/2500 1000 2500 1900 120 320 7.5 WC67Y-100/3200 1000 3200 2600 120 320 7.5 WC67Y-100/4000 1000 4000 3200 120 320 7.5 WC67Y-100/5000 1000 5000 4000 120 320 7.5 WC67Y-125/2500 1250 2500 2050 130 320 7.5 WC67Y-125/3200 1250 3200 2600 130 320 7.5 WC67Y-125/4000 1250 4000 3200 130 320 7.5 WC67Y-125/5000 1250 5000 4000 120 320 7.5 WC67Y-160/3200 1600 3200 4800 200 320 11 WC67Y-160/4000 1600 4000 2600 200 320 11 WC67Y-160/5000 1600 5000 3200 200 320 15 WC67Y-160/6000 1600 6000 4000 200 320 15 WC67Y-200/3200 2000 3200 4800 200 320 15 WC67Y-200/4000 2000 4000 2600 200 320 15 WC67Y-200/5000 2000 5000 3200 200 320 15 WC67Y-200/6000 2000 6000 4000 200 320 15 WC67Y-250/3200 2500 3200 4800 200 320 18.5 WC67Y-250/4000 2500 4000 2600 250 400 18.5 WC67Y-250/5000 2500 5000 3200 250 400 18.5 WC67Y-250/6000 2500 6000 4000 250 400 18.5 WC67Y-300/3200 3000 3200 4800 250 400 22 WC67Y-300/4000 3000 4000 3200 250 400 22 WC67Y-300/5000 3000 5000 4000 250 400 22 WC67Y-300/6000 3000 6000 4800 250 400 22 WC67Y-400/4000 400 4000 3200 320 400 22 WC67Y-400/5000 400 5000 4000 320 400 22 WC67Y-400/6000 400 6000 4800 320 400 22
