• Model NO.：CNC-YH616L
• Trademark：Jiangnan Machinery
• Origin：China

Basic Info.

Model NO. CNC-YH616L Trademark Jiangnan Machinery Origin China

Product Description

Product Category: CNC Pressure Spring Machine


Name: CNC-YH616

Technical Parameters:




Axes Count	6
Wire Diameter	Ø0.3-Ø2.0mm
Outside Diameter	Ø40mm
Wire Feed Length	Unlimited
Wire Feed Speed	0-110m/min
Production Rate	500pcs/min
Wire Feed Axle	3KW
Outside Diameter Axle 1	0.45KW
Outside Diameter Axle 2	0.45KW
Cutter Axle 1	0.45KW
Cutter Axle 2	0.45KW
Pitch Axle	0.2KW
Power	380V±10%V50Hz
Dimensions(L*W*H)	680*620*1480 mm
Weight	550 (Kg)

  Functions and Features:


1.It combines the design of Jiangnan Computer Control System and servo motor imported from Japan.
2.The computer offers the language of both Chinese and English, featuring easy operation and accurate positioning.
Computer can control three to eight servo motor,all motor can be synchronous or run alone.
3.The precise detection and tracking device is utilized to stop automatically in case of unqualifed products.
4.The outside diameter and angles can be modified according to the working condition on the fluorescent screen.
5 Automatic mechanical design of self-lubricating oil supply ensures the equipment operation for a long time.
6.In the event of the wireless,disconnection,tangled lines, automatic machine halt and automatic acceleration make production efficient.
7.Processing scope includes torsion spring,straight spring,rectangle spring,wire forming,volute spring,spring and various fancy spring,etc.
