30ton Hot Chamber Die Casting Machine for Zamak Alloy (J213D)
Ningbo Yinzhou Hybers Imp.& Exp. Co., Ltd.- Control Type:PLC
- Customized:Non-Customized
- Condition:New
- Automatic Grade:Automatic
- Certification:CE
- Type:Special Casting
Base Info
- Model NO.:J213D
- Die Locking Force:30tons
- Motor Voltage:380V, 220V, 415V
- Application:Zinc Alloy, Zamak Alloy, Pb Alloy
- Metal Melting Furnace Selection:Electric, Natural Gas, Diesel
- Controlling:PLC and Contact Screen
- Transport Package:20gp Full Container Load
- Specification:SGS
- Trademark:YINSHAN
- Origin:Ningbo. China
- HS Code:8454309000
- Production Capacity:600sets,Year
Description
Basic Info.
Model NO. J213D Die Locking Force 30tons Motor Voltage 380V, 220V, 415V Application Zinc Alloy, Zamak Alloy, Pb Alloy Metal Melting Furnace Selection Electric, Natural Gas, Diesel Controlling PLC and Contact Screen Transport Package 20gp Full Container Load Specification SGS Trademark YINSHAN Origin Ningbo. China HS Code 8454309000 Production Capacity 600sets/YearProduct Description
J213D(30Ton)300kN Hot Chamber Die Casting Machine Suitable for zinc alloy, Pb alloy parts die cast.PLC control FeaturesLocking force: 30TonTie bar distance: 240x240mmDie height: 120-320mmMax. weight of shot (zinc): 0.6kgsMax. casting area: 134cm2Motor power: 7.5kWProject | unit | J213D |
Die locking force | KN | 300 |
Stroke of moving platen | mm | 200 |
Inner space between the bars (H× V) | mm | 240× 240 |
Thickness of die block (Min. -Max) | mm | 120-320 |
Injection force | KN | 30 |
Injection stroke | mm | 110 |
Injection position | mm | 0, -40 |
Ejection force | KN | 35 |
Ejection stroke | mm | 50 |
Diameter of shot sleeve | mm | 45 |
Max Projecting area of casting | cm 2 | 132 |
Working pressure of vane pump | MPa | 7 |
Motor power | KW | 7.5 |
Dosage of fluid metal per shot(Zinc) | kg | 0.6 |
Effective volume of crucible (Zinc) | kg | 160 |
Oil consumption of burner | kg/h | 1.5-6.0 |
Volume of oil tank | L | 320 |
Machine weight | kg | 2800 |
Overall dimensions (L× W× H) | mm | 3407× 1273× 2542 |
