• Trademark：SUNNY
• Origin：China
• HS Code：84799090
• Production Capacity：Customized Capacity

Basic Info.

Trademark SUNNY Origin China HS Code 84799090 Production Capacity Customized Capacity

Product Description

Products Description

1. Main Technical Specification
    1) The heat exchange capacity can reach 70×10⁴ kcal/h.
    2) The outside of the heat exchange tube is N2+H2 protective gas, the flow is 30000Nm³/h, the entrance temperature is 200ºC, the exit temperature is 120ºC.
    3) The inside of the heat exchange tube is cooling water; the flow is 70t/h, the entrance temperature is max.34.5ºC, exit temperature is 44.5ºC.

2. The gas movement mode of the heat exchanger: Orthogonal countercurrent single stroke.

3. Material requirement: the heat transmit tube is copper, with aluminum fin.

4. Sealing performance test:
    1) During the manufacture of the heat exchanger, it need to make sure that each weld seam has done the kerosene leakage test, the testing period is no less than 45 minutes. The heat exchanger is qualified when there is no leakage after inspection.
    2) After finish the assembly of the whole heat exchanger, it need to do the sealing performance test before enter into market, the water sealing test pressure is 0.8MPa, it is qualified when there is no any leakage.

5. The joint area of the heat exchange equipped with matching flange.

6. Weight: 900KGS

Packing & Shipping

1. Export standard wooden cases packed in suitable container.

2. Cooperate with reliable shipping company to ensure the delivery time.

3. Customized Packing is allowed.



Certificate and Award

SUNNY has been awarded as "National Hi-tech Enterprise" by the Government and has undertook "China

Torch Plan" (CTP, by China government) of "Wide strip continuous galvanizing process equipment

completed". At the same time, SUNNY has become a famous trademark of China by China Trademark

Bureau.

GB/T 19001-2016/ISO 9001:2015




Aftersale Service:

We can provide site technical support as well as remote technical support;

1. Installation, debug
After equipment reached the workshop of customer, we will responsible for the design, manufacture and supply of contracted equipment, as well as the supervising of erection and commissioning. The buyer need to supply accommodation of our engineer, food, and local transportation on working day.

2. Training
Our company offer technology training to customer including theoretical knowledge, equipment principle, operation and maintenance. We will dispatch a team to seller's CGL line, to conduct the on line training.

3. Quality guarantee
The equipment will be designed and manufactured according to relational professional regulations or standard. The quality will be tracking control by professional quality control engineer of Seller.

Our Vision
To be worldwide known equipment supplier by our advanced strip processing technology and superior services.

Our Mission
Based on the strip processing technology, provide the advanced strip solution for customers at home and aboard.

Our Core Value
Integrity, Respect, Fairness, Diversity

Our Spirit
Innovation, Solidarity, High Efficiency

Exhibition:
ITIF ASIA & PAKISTAN IMPORT & EXPORT FAIR


Vietnam ISME Exhibition


Iran International Industry Exhibition
